Commercial
Insulated
Pin Terminals

Filter
1121-09-08812
1121-09-08812
1121-09-08812
0.385" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1156-09-0515
1156-09-0515
1156-09-0515
0.609" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Green NO
1156-09-0517
1156-09-0517
1156-09-0517
0.609" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Violet NO
1111R-09-04417
1111R-09-04417
1111R-09-04417
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Violet YES
1131-09-0313
1131-09-0313
1131-09-0313
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Orange NO
1178R-09-0318
1178R-09-0318
1178R-09-0318
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Gold - - PTFE Gray NO
1178R-09-0319
1178R-09-0319
1178R-09-0319
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Gold - - PTFE White YES
1131-09-0314
1131-09-0314
1131-09-0314
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Yellow NO
1131-09-0315
1131-09-0315
1131-09-0315
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Green YES
1131-09-0317
1131-09-0317
1131-09-0317
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Violet YES
1111R-09-0411
1111R-09-0411
1111R-09-0411
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Brown NO
1111R-09-0413
1111R-09-0413
1111R-09-0413
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1111R-09-0416
1111R-09-0416
1111R-09-0416
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Blue YES
1110-09-0115
1110-09-0115
1110-09-0115
0.375" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Silver - - PTFE Green YES
1111R-09-0417
1111R-09-0417
1111R-09-0417
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Violet YES
1111R-09-0419
1111R-09-0419
1111R-09-0419
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1111-09-08813
1111-09-08813
1111-09-08813
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1123-09-04410
1123-09-04410
1123-09-04410
1.197" 0.050 TIP/SLOTTED Press Fit 1/2 0.158 Brass Bright Tin - - PTFE Black YES
1135-09-04411
1135-09-04411
1135-09-04411
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Brown NO
1135-09-04412
1135-09-04412
1135-09-04412
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Red NO
