Commercial
Insulated
Pin Terminals

Filter
1110-47-0513
1110-47-0513
1110-47-0513
0.865" 0.050 Pin/Pin Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Orange NO
1111-47-0113
1111-47-0113
1111-47-0113
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.221 Brass Silver - - PTFE Orange NO
1110-47-08818
1110-47-08818
1110-47-08818
0.865" 0.050 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Gray NO
1127-47-04415
1127-47-04415
1127-47-04415
0.844" - - Swage Mount 3/32 0.104 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Green YES
1127-47-04418
1127-47-04418
1127-47-04418
0.844" - - Swage Mount 3/32 0.104 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1125-47-04413
1125-47-04413
1125-47-04413
0.616" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin ZINC Brass PTFE Orange NO
1175-463-0511
1175-463-0511
1175-463-0511
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Brown NO
1175-463-0319
1175-463-0319
1175-463-0319
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE White YES
1175-463-0317
1175-463-0317
1175-463-0317
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Violet YES
1175-463-0314
1175-463-0314
1175-463-0314
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Yellow NO
1175-463-08811
1175-463-08811
1175-463-08811
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Brown NO
1175-463-08814
1175-463-08814
1175-463-08814
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Yellow NO
1175-463-08817
1175-463-08817
1175-463-08817
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Violet NO
1175-463-08818
1175-463-08818
1175-463-08818
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Gray NO
1175-463-0414
1175-463-0414
1175-463-0414
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Yellow NO
1175-463-04415
1175-463-04415
1175-463-04415
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Green YES
1175-463-0312
1175-463-0312
1175-463-0312
0.424" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Red NO
1175-462-0512
1175-462-0512
1175-462-0512
0.392" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Red NO
1175-462-0513
1175-462-0513
1175-462-0513
0.392" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Orange NO
1175-462-0515
1175-462-0515
1175-462-0515
0.392" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Green NO
