Commercial
Insulated
Pin Terminals

Filter
1175-461-0114
1175-461-0114
1175-461-0114
0.361" - - PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Yellow NO
1175-461-0112
1175-461-0112
1175-461-0112
0.361" - - PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Red NO
1102-46-0510
1102-46-0510
1102-46-0510
0.556" - - Press Fit 1/16 0.152 Brass Electro Solder - - PTFE Black NO
1154R-46-0315
1154R-46-0315
1154R-46-0315
0.478" 0.050 Pin/Slotted Press Fit 11/32 0.158 Brass Gold - - PTFE Green YES
1102-46-0512
1102-46-0512
1102-46-0512
0.556" - - Press Fit 1/16 0.152 Brass Electro Solder - - PTFE Red NO
1126-46-08814
1126-46-08814
1126-46-08814
1.343" - - 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead ZINC Brass PTFE Yellow NO
1154R-46-0518
1154R-46-0518
1154R-46-0518
0.478" 0.050 Pin/Slotted Press Fit 11/32 0.158 Brass Electro Solder - - PTFE Gray NO
1127-46-0117
1127-46-0117
1127-46-0117
0.813" - - Swage Mount 1/16 0.104 Brass Silver ZINC Brass DIALLYL PHTHALATE Violet YES
1102-46-0418
1102-46-0418
1102-46-0418
0.556" - - Press Fit 1/16 0.152 Brass Electro-Tin - - PTFE Gray NO
1125-46-0314
1125-46-0314
1125-46-0314
0.718" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Gold ZINC Brass PTFE Yellow NO
1127-46-0116
1127-46-0116
1127-46-0116
0.813" - - Swage Mount 1/16 0.104 Brass Silver ZINC Brass DIALLYL PHTHALATE Blue YES
1154R-46-0314
1154R-46-0314
1154R-46-0314
0.478" 0.050 Pin/Slotted Press Fit 11/32 0.158 Brass Gold - - PTFE Yellow NO
1127-46-0115
1127-46-0115
1127-46-0115
0.813" - - Swage Mount 1/16 0.104 Brass Silver ZINC Brass DIALLYL PHTHALATE Green YES
1125-46-0313
1125-46-0313
1125-46-0313
0.718" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Gold ZINC Brass PTFE Orange NO
1111-22-0518
1111-22-0518
1111-22-0518
0.437" 0.047 DOUBLE Turret/Tip Press Fit 1/32 0.140 Brass Electro Solder - - PTFE Gray NO
1111-22-08813
1111-22-08813
1111-22-08813
0.437" 0.047 DOUBLE Turret/Tip Press Fit 1/32 0.140 Brass Bright Tin-Lead - - PTFE Orange NO
1160-22-0415
1160-22-0415
1160-22-0415
0.350" - - Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Green YES
1160-22-0411
1160-22-0411
1160-22-0411
0.350" - - Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Brown NO
1111-22-08810
1111-22-08810
1111-22-08810
0.437" 0.047 DOUBLE Turret/Tip Press Fit 1/32 0.140 Brass Bright Tin-Lead - - PTFE Black NO
1100R-22-0510
1100R-22-0510
1100R-22-0510
0.310" 0.040 - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Black NO
