Commercial
Non-Insulated
Terminals

Filter
09-0043-2-04
09-0043-2-04
09-0043-2-04
0.249" - - Swage Mount 0.099" 1/16 0.094 Brass Electro-Tin YES
09-0342-1-04
09-0342-1-04
09-0342-1-04
0.249" - - Swage Mount 0.062" 1/32 0.073 Brass Electro-Tin YES
10-408-4-04
10-408-4-04
10-408-4-04
0.477" - - Swage Mount 0.165" 1/8 0.116 Brass Electro-Tin YES
10-893-1-03
10-893-1-03
10-893-1-03
0.951" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Gold YES
10-903-2-04
10-903-2-04
10-903-2-04
0.282" - - Swage Mount 0.094" 1/16 0.063 Brass Electro-Tin YES
10-603-2-04
10-603-2-04
10-603-2-04
0.526" - - Swage Mount 0.105" 1/16 0.116 Brass Electro-Tin YES
10-891-1-04
10-891-1-04
10-891-1-04
0.351" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Electro-Tin YES
10-560-4-04
10-560-4-04
10-560-4-04
0.712" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.116 Brass Electro-Tin YES
10-471-2-04
10-471-2-04
10-471-2-04
0.240" - - Swage Mount 0.084" 1/16 0.067 Brass Electro-Tin YES
10-413-2-04
10-413-2-04
10-413-2-04
0.238" - - Swage Mount 0.082" 1/16 0.052 Brass Electro-Tin YES
10-8009-2-03
10-8009-2-03
10-8009-2-03
0.297" 0.062 - Swage Mount 0.084" 1/16 0.067 Brass Gold YES
09-0217-5-095
09-0217-5-095
09-0217-5-095
0.445" - - Swage Mount 0.165" 1/8 0.094 Brass Hot Solder Dip NO
09-0183-4-095
09-0183-4-095
09-0183-4-095
0.250" 0.030 - Swage Mount 0.125" 3/32 0.062 Brass Hot Solder Dip NO
10-101-8-095
10-101-8-095
10-101-8-095
0.374" - - Swage Mount 0.270" 1/4 0.076 Brass Hot Solder Dip NO
10-418-3A-05
10-418-3A-05
10-418-3A-05
0.654" - Turret/Turret Swage Mount 0.123" 3/32 0.120 Brass Electro Solder NO
10-803-3-095
10-803-3-095
10-803-3-095
0.488" 0.040 TURRET/PIN Swage Mount 0.113" 3/32 0.076 Brass Hot Solder Dip NO
10-803-1-095
10-803-1-095
10-803-1-095
0.426" 0.040 TURRET/PIN Swage Mount 0.051" 1/32 0.076 Brass Hot Solder Dip NO
10-138-3-035
10-138-3-035
10-138-3-035
0.375" - - Swage Mount 0.125" 3/32 0.067 Brass Gold YES
09-0320-1-05
09-0320-1-05
09-0320-1-05
0.281" - - Press Fit/Solder 0.195" 3/16 TO 7/32 0.055 Brass Electro Solder NO
10-305-2-05
10-305-2-05
10-305-2-05
0.297" - - Swage Mount 0.109" 1/16 0.113 Brass Electro Solder NO
