Commercial
Non-Insulated
Terminals

Filter
10-507-6-05
10-507-6-05
10-507-6-05
0.703" - Turret/Turret Swage Mount 0.234" 3/16 0.185 Brass Electro Solder NO
10-507-4-05
10-507-4-05
10-507-4-05
0.641" - Turret/Turret Swage Mount 0.172" 1/8 0.185 Brass Electro Solder NO
09-8816-2A-01
09-8816-2A-01
09-8816-2A-01
0.324" 0.040 - Swage Mount 0.100" 1/16 0.094 Brass Silver YES
09-8816-2A-044
09-8816-2A-044
09-8816-2A-044
0.324" 0.040 - Swage Mount 0.100" 1/16 0.094 Brass Bright Tin YES
09-8816-2A-03
09-8816-2A-03
09-8816-2A-03
0.324" 0.040 - Swage Mount 0.100" 1/16 0.094 Brass Gold YES
10-809-4-05
10-809-4-05
10-809-4-05
0.258" - - Swage Mount 0.172" 1/8 0.116 Brass Electro Solder NO
10-809-2-03
10-809-2-03
10-809-2-03
0.258" - - Swage Mount 0.109" 1/16 0.116 Brass Gold YES
10-809-2-05
10-809-2-05
10-809-2-05
0.258" - - Swage Mount 0.109" 1/16 0.116 Brass Electro Solder NO
10-809-3-05
10-809-3-05
10-809-3-05
0.258" - - Swage Mount 0.141" 3/32 0.116 Brass Electro Solder NO
10-809-1-01
10-809-1-01
10-809-1-01
0.258" - - Swage Mount 0.078" 1/32 0.116 Brass Silver YES
10-809-3-044
10-809-3-044
10-809-3-044
0.258" - - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin YES
19-246-2-03
19-246-2-03
19-246-2-03
0.468" - - Swage Mount 0.109" 1/16 0.116 LEADED Red Brass Gold YES
19-246-2-035
19-246-2-035
19-246-2-035
0.468" - - Swage Mount 0.109" 1/16 0.116 LEADED Red Brass Gold YES
10-111-4-01
10-111-4-01
10-111-4-01
0.346" - - Swage Mount 0.165" 1/8 0.094 Brass Silver YES
10-111-2-035
10-111-2-035
10-111-2-035
0.286" - - Swage Mount 0.105" 1/16 0.094 Brass Gold YES
09-9503-2-04
09-9503-2-04
09-9503-2-04
0.356" 0.062 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Electro-Tin YES
09-9502-2-088
09-9502-2-088
09-9502-2-088
0.356" 0.040 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Bright Tin-Lead NO
09-9504-2-01
09-9504-2-01
09-9504-2-01
0.356" 0.045 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Silver YES
10-837-2-01
10-837-2-01
10-837-2-01
0.438" 0.050 Pin/Pin Swage Mount 0.094" 1/16 0.111 Brass Silver YES
10-837-8-03
10-837-8-03
10-837-8-03
0.626" 0.050 Pin/Pin Swage Mount 0.281" 1/4 0.111 Brass Gold YES
