Commercial
Non-Insulated
Terminals

Filter
10-838-4-03
10-838-4-03
10-838-4-03
0.688" 0.050 Pin/Pin Swage Mount 0.156" 1/8 0.111 Brass Gold YES
10-311-2-04
10-311-2-04
10-311-2-04
0.421" - - Swage Mount 0.109" 1/16 0.116 Brass Electro-Tin YES
09-8188-1-05
09-8188-1-05
09-8188-1-05
0.137" 0.025 - Swage Mount 0.047" 1/32 0.035 Brass Electro Solder NO
09-0150-2-04
09-0150-2-04
09-0150-2-04
0.154" - - Swage Mount 0.084" 1/16 0.037 Brass Electro-Tin YES
10-372-2-088
10-372-2-088
10-372-2-088
0.240" - - Swage Mount 0.084" 1/16 0.064 Brass Bright Tin-Lead NO
10-434-1-04
10-434-1-04
10-434-1-04
0.343" - - Swage Mount 0.075" 1/32 0.189 Brass Electro-Tin YES
10-823-2-035
10-823-2-035
10-823-2-035
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Gold YES
10-127-1-03
10-127-1-03
10-127-1-03
0.265" - - Press Fit/Solder 0.130" 1/16 TO 3/32 0.055 Brass Gold YES
10-909-1-03
10-909-1-03
10-909-1-03
0.359" - - Press Fit/Solder 0.134" 1/8 0.096 Brass Gold YES
09-0368-4-01
09-0368-4-01
09-0368-4-01
0.422" - - Swage Mount 0.172" 1/8 0.266 Brass Silver YES
10-432-8-035
10-432-8-035
10-432-8-035
0.730" - - Swage Mount 0.293" 1/4 0.161 Brass Gold YES
10-470-2-03
10-470-2-03
10-470-2-03
0.480" - - Swage Mount 0.105" 1/16 0.154 Brass Gold YES
10-835-3-04
10-835-3-04
10-835-3-04
0.563" 0.050 - Swage Mount 0.125" 3/32 0.064 Brass Electro-Tin YES
10-562-2-05
10-562-2-05
10-562-2-05
0.573" - Double Turret/Double Turret Swage Mount 0.105" 1/16 0.159 Brass Electro Solder NO
10-515-2-03
10-515-2-03
10-515-2-03
0.871" 0.094 TURRET/PIN Swage Mount 0.105" 1/16 0.185 Brass Gold YES
10-416-4-03
10-416-4-03
10-416-4-03
0.303" - - Swage Mount 0.147" 1/8 0.064 Brass Gold YES
09-8572-2-05
09-8572-2-05
09-8572-2-05
0.764" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
10-453-1-088
10-453-1-088
10-453-1-088
0.145" - - Swage Mount 0.051" 1/32 0.052 Brass Bright Tin-Lead NO
10-401-3-035
10-401-3-035
10-401-3-035
0.281" - - Swage Mount 0.125" 3/32 0.067 Brass Gold YES
10-504-4-04
10-504-4-04
10-504-4-04
0.563" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.094 Brass Electro-Tin YES
