Commercial
Non-Insulated
Terminals

Filter
10-604-4-095
10-604-4-095
10-604-4-095
0.859" - - Swage Mount 0.172" 1/8 0.266 Brass Hot Solder Dip NO
10-604-6-05
10-604-6-05
10-604-6-05
0.921" - - Swage Mount 0.234" 3/16 0.266 Brass Electro Solder NO
10-519-2-095
10-519-2-095
10-519-2-095
1.030" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.266 Brass Hot Solder Dip NO
10-211-4-044
10-211-4-044
10-211-4-044
0.672" - - Swage Mount 0.172" 1/8 0.266 Brass Bright Tin YES
10-211-2-044
10-211-2-044
10-211-2-044
0.609" - - Swage Mount 0.109" 1/16 0.266 Brass Bright Tin YES
10-211-4-088
10-211-4-088
10-211-4-088
0.672" - - Swage Mount 0.172" 1/8 0.266 Brass Bright Tin-Lead NO
10-211-6-04
10-211-6-04
10-211-6-04
0.734" - - Swage Mount 0.234" 3/16 0.266 Brass Electro-Tin YES
10-521-5-035
10-521-5-035
10-521-5-035
0.648" 0.094 Pin/Pin Swage Mount 0.195" 5/32 0.185 Brass Gold YES
10-521-4-095
10-521-4-095
10-521-4-095
0.618" 0.094 Pin/Pin Swage Mount 0.165" 1/8 0.185 Brass Hot Solder Dip NO
10-522-5-095
10-522-5-095
10-522-5-095
0.664" - Turret/Turret Swage Mount 0.195" 5/32 0.206 Brass Hot Solder Dip NO
10-549-3-03
10-549-3-03
10-549-3-03
0.814" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.206 Brass Gold YES
10-549-4-095
10-549-4-095
10-549-4-095
0.844" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.206 Brass Hot Solder Dip NO
10-226-1-01
10-226-1-01
10-226-1-01
0.435" - - Swage Mount 0.075" 1/32 0.206 Brass Silver YES
10-508-3-04
10-508-3-04
10-508-3-04
0.569" - TURRET/DOUBLE TURRET Swage Mount 0.125" 3/32 0.206 Brass Electro-Tin YES
10-526-4-04
10-526-4-04
10-526-4-04
0.687" - TURRET/DOUBLE TURRET Swage Mount 0.156" 1/8 0.206 Brass Electro-Tin YES
14-350-5-01
14-350-5-01
14-350-5-01
0.716" - - Swage Mount 0.195" 5/32 0.196 LEADED Red Brass Silver YES
14-351-2-03
14-351-2-03
14-351-2-03
0.434" - - Swage Mount 0.109" 1/16 0.196 LEADED Red Brass Gold YES
10-532-1-095
10-532-1-095
10-532-1-095
0.543" - Double Turret/Double Turret Swage Mount 0.075" 1/32 0.159 Brass Hot Solder Dip NO
10-530-1-04
10-530-1-04
10-530-1-04
0.544" - TURRET/DOUBLE TURRET Swage Mount 0.075" 1/32 0.159 Brass Electro-Tin YES
10-532-5-03
10-532-5-03
10-532-5-03
0.663" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.159 Brass Gold YES
