Commercial
Non-Insulated
Terminals

Filter
09-7131-2-01
09-7131-2-01
09-7131-2-01
0.613" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Silver YES
09-7133-2-01
09-7133-2-01
09-7133-2-01
1.013" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Silver YES
09-7188-2-04
09-7188-2-04
09-7188-2-04
0.276" - - RIVET MOUNT 0.091" 1/16 0.052 Brass Electro-Tin YES
09-7136-2-04
09-7136-2-04
09-7136-2-04
0.367" 0.040 - RIVET MOUNT 0.087" 1/16 0.044 Brass Electro-Tin YES
09-7144-1-044
09-7144-1-044
09-7144-1-044
0.238" 0.027 (+0.000/-0.003) - RIVET MOUNT 0.114" 3/32 0.035 Brass Bright Tin YES
09-7152-2-044
09-7152-2-044
09-7152-2-044
0.213" 0.030 - RIVET MOUNT 0.093" 1/16 0.035 Brass Bright Tin YES
09-7177-1B-044
09-7177-1B-044
09-7177-1B-044
0.278" - - RIVET MOUNT 0.074" 3/64 0.047 Brass Bright Tin YES
09-7181-1-04
09-7181-1-04
09-7181-1-04
0.197" - - RIVET MOUNT 0.052" 1/32 0.036 Brass Electro-Tin YES
09-7149-3-044
09-7149-3-044
09-7149-3-044
0.344" 0.045 - RIVET MOUNT 0.120" 3/32 0.048 Brass Bright Tin YES
09-7121-1-044
09-7121-1-044
09-7121-1-044
0.286" 0.025 - RIVET MOUNT 0.052" 1/32 0.035 Brass Bright Tin YES
09-7181-4-035
09-7181-4-035
09-7181-4-035
0.291" - - RIVET MOUNT 0.146" 1/8 0.036 Brass Gold YES
09-7105-1B-035
09-7105-1B-035
09-7105-1B-035
0.166" 0.020 - RIVET MOUNT 0.067" 3/64 0.035 Brass Gold YES
09-7170-2B-035
09-7170-2B-035
09-7170-2B-035
0.194" - - RIVET MOUNT 0.095" 19/256 0.035 Brass Gold YES
09-7157-2-035
09-7157-2-035
09-7157-2-035
0.6315" 0.025 SQ. - RIVET MOUNT 0.126" 3/32 0.0625 Brass Gold YES
09-7181-3-035
09-7181-3-035
09-7181-3-035
0.259" - - RIVET MOUNT 0.114" 3/32 0.036 Brass Gold YES
09-7162-1-035
09-7162-1-035
09-7162-1-035
0.230" 0.024 (+0.001/-0.000) - RIVET MOUNT 0.035" 1/100 0.032 Brass Gold YES
09-7111-2-035
09-7111-2-035
09-7111-2-035
0.336" 0.026 - RIVET MOUNT 0.082" 1/16 0.032 Brass Gold YES
09-7143-1-035
09-7143-1-035
09-7143-1-035
0.493" 0.040 - RIVET MOUNT 0.088" 1/16 0.044 Brass Gold YES
09-7125-1-035
09-7125-1-035
09-7125-1-035
0.382" 0.0405 - RIVET MOUNT 0.056" 1/32 0.044 Brass Gold YES
09-7196-2-035
09-7196-2-035
09-7196-2-035
0.281" 0.030 - RIVET MOUNT 0.083" 1/16 0.035 Brass Gold YES
