Commercial
Non-Insulated
Terminals

Filter
10-227-2-01
10-227-2-01
10-227-2-01
0.240" - - Swage Mount 0.084" 1/16 0.043 Brass Silver YES
10-940-1-01
10-940-1-01
10-940-1-01
0.250" - - Swage Mount 0.062" 1/32 0.0635 Brass Silver YES
09-8301-11-01
09-8301-11-01
09-8301-11-01
0.208" 0.017 - Solder 0.035" 1/64 0.0225 Brass Silver YES
10-205-1-01
10-205-1-01
10-205-1-01
0.435" - - Swage Mount 0.075" 1/32 0.116 Brass Silver YES
10-815-1-05
10-815-1-05
10-815-1-05
0.275" - - Swage Mount 0.075" 1/32 0.1495 Brass Electro Solder NO
14-986-2-088
14-986-2-088
14-986-2-088
0.275" 0.050 - Swage Mount 0.094" 1/16 0.033 LEADED Red Brass Bright Tin-Lead NO
14-986-2-05
14-986-2-05
14-986-2-05
0.275" 0.050 - Swage Mount 0.094" 1/16 0.033 LEADED Red Brass Electro Solder NO
14-986-2-044
14-986-2-044
14-986-2-044
0.275" 0.050 - Swage Mount 0.094" 1/16 0.033 LEADED Red Brass Bright Tin YES
14-948-3-01
14-948-3-01
14-948-3-01
0.298" - - Swage Mount 0.125" 3/32 0.064 LEADED Red Brass Silver YES
14-948-1-05
14-948-1-05
14-948-1-05
0.235" - - Swage Mount 0.062" 1/32 0.064 LEADED Red Brass Electro Solder NO
14-947-4-044
14-947-4-044
14-947-4-044
0.329" - - Swage Mount 0.156" 1/8 0.063 LEADED Red Brass Bright Tin YES
14-947-4-01
14-947-4-01
14-947-4-01
0.329" - - Swage Mount 0.156" 1/8 0.063 LEADED Red Brass Silver YES
14-947-3-088
14-947-3-088
14-947-3-088
0.298" - - Swage Mount 0.125" 3/32 0.063 LEADED Red Brass Bright Tin-Lead NO
14-947-3-05
14-947-3-05
14-947-3-05
0.298" - - Swage Mount 0.125" 3/32 0.063 LEADED Red Brass Electro Solder NO
14-947-3-044
14-947-3-044
14-947-3-044
0.298" - - Swage Mount 0.125" 3/32 0.063 LEADED Red Brass Bright Tin YES
14-947-3-035
14-947-3-035
14-947-3-035
0.298" - - Swage Mount 0.125" 3/32 0.063 LEADED Red Brass Gold YES
10-502-2-05
10-502-2-05
10-502-2-05
0.350" - TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.076 Brass Electro Solder NO
10-815-2-05
10-815-2-05
10-815-2-05
0.305" - - Swage Mount 0.105" 1/16 0.1495 Brass Electro Solder NO
09-6016-2-05
09-6016-2-05
09-6016-2-05
0.710" 0.025 SQ. - Press Fit/Solder 0.080" 1/16 0.055 Brass Electro Solder NO
10-972-2-05
10-972-2-05
10-972-2-05
0.852" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
