Commercial
Non-Insulated
Terminals

Filter
10-8016-3-01
10-8016-3-01
10-8016-3-01
0.643" 0.080 - Swage Mount 0.113" 3/32 0.094 Brass Silver YES
10-311-4-05
10-311-4-05
10-311-4-05
0.484" - - Swage Mount 0.172" 1/8 0.116 Brass Electro Solder NO
09-8148-1-05
09-8148-1-05
09-8148-1-05
0.633" 0.030 - Swage Mount 0.053" 1/32 0.067 Brass Electro Solder NO
09-7108-1A-05
09-7108-1A-05
09-7108-1A-05
0.355" 0.025 - RIVET MOUNT 0.035" 1/100 0.033 Brass Electro Solder NO
10-442-3-05
10-442-3-05
10-442-3-05
0.695" - SLOTTED/DOUBLE TURRET Swage Mount 0.135" 3/32 0.116 Brass Electro Solder NO
10-833-1-01
10-833-1-01
10-833-1-01
0.376" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Silver YES
09-8405-8-088
09-8405-8-088
09-8405-8-088
0.640" - - Swage Mount 0.297" 1/4 0.096 Brass Bright Tin-Lead NO
10-915-3A-05
10-915-3A-05
10-915-3A-05
0.275" 0.025 - Swage Mount 0.125" 3/32 0.043 Brass Electro Solder NO
09-8061-1-05
09-8061-1-05
09-8061-1-05
1.111" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Electro Solder NO
10-323-3-01
10-323-3-01
10-323-3-01
0.271" - - Swage Mount 0.115" 3/32 0.076 Brass Silver YES
09-7186-4-044
09-7186-4-044
09-7186-4-044
0.300" - - RIVET MOUNT 0.150" 1/8 0.044 Brass Bright Tin YES
10-460-3-044
10-460-3-044
10-460-3-044
0.396" - - Swage Mount 0.115" 3/32 0.063 Brass Bright Tin YES
09-0277-2-044
09-0277-2-044
09-0277-2-044
0.238" - - Swage Mount 0.082" 1/16 0.052 Brass Bright Tin YES
10-225-6-044
10-225-6-044
10-225-6-044
0.363" - - Swage Mount 0.209" 3/16 0.067 Brass Bright Tin YES
09-8059-1-05
09-8059-1-05
09-8059-1-05
0.551" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Electro Solder NO
09-7010-3-044
09-7010-3-044
09-7010-3-044
0.265" 0.050 - Swage Mount 0.125" 3/32 0.055 Brass Bright Tin YES
10-706-6-044
10-706-6-044
10-706-6-044
0.545" - - 4-40 - - 4-40 THREAD Brass Bright Tin YES
10-426-3-05
10-426-3-05
10-426-3-05
0.354" - - Swage Mount 0.135" 3/32 0.094 Brass Electro Solder NO
10-542-3-05
10-542-3-05
10-542-3-05
0.488" - TURRET/DOUBLE TURRET Swage Mount 0.125" 3/32 0.094 Brass Electro Solder NO
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
