Commercial
Non-Insulated
Terminals

Filter
10-489-3-035
10-489-3-035
10-489-3-035
0.281" - - Swage Mount 0.125" 3/32 0.067 Brass Gold YES
10-489-3-03
10-489-3-03
10-489-3-03
0.281" - - Swage Mount 0.125" 3/32 0.067 Brass Gold YES
10-916-3-044
10-916-3-044
10-916-3-044
0.433" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Bright Tin YES
10-916-1-035
10-916-1-035
10-916-1-035
0.371" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Gold YES
10-502-6-05
10-502-6-05
10-502-6-05
0.475" - TURRET/DOUBLE TURRET Swage Mount 0.207" 3/16 0.076 Brass Electro Solder NO
10-502-6-04
10-502-6-04
10-502-6-04
0.475" - TURRET/DOUBLE TURRET Swage Mount 0.207" 3/16 0.076 Brass Electro-Tin YES
10-503-3-04
10-503-3-04
10-503-3-04
0.463" - Double Turret/Double Turret Swage Mount 0.113" 3/32 0.076 Brass Electro-Tin YES
10-906-3-035
10-906-3-035
10-906-3-035
0.261" - - Swage Mount 0.125" 3/32 0.0635 Brass Gold YES
09-8817-1-05
09-8817-1-05
09-8817-1-05
0.348" 0.031 - Solder 0.028" 1/64 0.043 Brass Electro Solder NO
10-906-3-01
10-906-3-01
10-906-3-01
0.261" - - Swage Mount 0.125" 3/32 0.0635 Brass Silver YES
10-504-2-095
10-504-2-095
10-504-2-095
0.501" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Hot Solder Dip NO
10-905-4-01
10-905-4-01
10-905-4-01
0.344" - - Swage Mount 0.156" 1/8 0.0635 Brass Silver YES
10-905-1-03
10-905-1-03
10-905-1-03
0.250" - - Swage Mount 0.062" 1/32 0.0635 Brass Gold YES
10-505-4-01
10-505-4-01
10-505-4-01
0.479" - TURRET/DOUBLE TURRET Swage Mount 0.156" 1/8 0.094 Brass Silver YES
10-506-3-035
10-506-3-035
10-506-3-035
0.406" - Turret/Turret Swage Mount 0.125" 3/32 0.120 Brass Gold YES
10-506-4-01
10-506-4-01
10-506-4-01
0.437" - Turret/Turret Swage Mount 0.156" 1/8 0.120 Brass Silver YES
09-8825-1-04
09-8825-1-04
09-8825-1-04
0.488" 0.020 - Solder 0.113" 1/64 TO 3/32 0.035 Brass Electro-Tin YES
10-506-6-01
10-506-6-01
10-506-6-01
0.500" - Turret/Turret Swage Mount 0.219" 3/16 0.120 Brass Silver YES
10-506-6-05
10-506-6-05
10-506-6-05
0.500" - Turret/Turret Swage Mount 0.219" 3/16 0.120 Brass Electro Solder NO
09-8153-1-044
09-8153-1-044
09-8153-1-044
0.242" 0.035 - Swage Mount 0.062" 1/32 0.0625 Brass Bright Tin YES
