Commercial
Insulated
Pin Terminals

Filter
1107-08-0117
1107-08-0117
1107-08-0117
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Silver - - PTFE Violet YES
1111-08-08819
1111-08-08819
1111-08-08819
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE White NO
1156-08-08819
1156-08-08819
1156-08-08819
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE White NO
1156-08-08817
1156-08-08817
1156-08-08817
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1123-08-0510
1123-08-0510
1123-08-0510
1.197" 0.050 TIP/SLOTTED Press Fit 15/32 0.158 Brass Electro Solder - - PTFE Black NO
1107-08-04419
1107-08-04419
1107-08-04419
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE White YES
1100-93-08810
1100-93-08810
1100-93-08810
0.315" 0.030 - Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Black NO
1107-08-04416
1107-08-04416
1107-08-04416
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Blue YES
1107-08-04415
1107-08-04415
1107-08-04415
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Green YES
1107-08-0416
1107-08-0416
1107-08-0416
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Blue YES
1107-08-0412
1107-08-0412
1107-08-0412
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Red NO
1100R-08-0515
1100R-08-0515
1100R-08-0515
0.250" 0.040 - Press Fit 1/16 0.091 Brass Electro Solder - - PTFE Green NO
1100-08-0414
1100-08-0414
1100-08-0414
0.250" 0.040 - Press Fit 3/64 0.091 Brass Electro-Tin - - PTFE Yellow NO
1100-08-0415
1100-08-0415
1100-08-0415
0.250" 0.040 - Press Fit 3/64 0.091 Brass Electro-Tin - - PTFE Green YES
1100R-08-0410
1100R-08-0410
1100R-08-0410
0.250" 0.040 - Press Fit 1/16 0.091 Brass Electro-Tin - - PTFE Black YES
1113R-08-0519
1113R-08-0519
1113R-08-0519
0.333" - - Press Fit 1/6 0.136 Brass Electro Solder - - PTFE White NO
1100R-08-0415
1100R-08-0415
1100R-08-0415
0.250" 0.040 - Press Fit 1/16 0.091 Brass Electro-Tin - - PTFE Green YES
1100R-08-0417
1100R-08-0417
1100R-08-0417
0.250" 0.040 - Press Fit 1/16 0.091 Brass Electro-Tin - - PTFE Violet YES
1102-08-04413
1102-08-04413
1102-08-04413
0.647" - - Press Fit 1/8 0.122 Brass Bright Tin - - PTFE Orange NO
1103-08-0510
1103-08-0510
1103-08-0510
0.320" - - Press Fit 3/32 0.152 Brass Electro Solder - - PTFE Black NO
