Commercial
Insulated
Pin Terminals

Filter
1130-05-0416
1130-05-0416
1130-05-0416
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro-Tin - - PTFE Blue YES
1125-05-04419
1125-05-04419
1125-05-04419
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin Electro-Tin Brass PTFE White YES
1112-05-0118
1112-05-0118
1112-05-0118
0.200" - - Press Fit 1/32 0.113 Brass Silver - - PTFE Gray NO
1155-05-0113
1155-05-0113
1155-05-0113
0.265" 0.040 - Press Fit 1/16 0.086 Brass Silver - - PTFE Orange NO
1110R-05-08811
1110R-05-08811
1110R-05-08811
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Brown NO
1130-05-0418
1130-05-0418
1130-05-0418
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro-Tin - - PTFE Gray NO
1127-05-04415
1127-05-04415
1127-05-04415
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin Electro-Tin Brass DIALLYL PHTHALATE Green YES
1127-05-04413
1127-05-04413
1127-05-04413
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin Electro-Tin Brass DIALLYL PHTHALATE Orange YES
1127-05-04412
1127-05-04412
1127-05-04412
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin Electro-Tin Brass DIALLYL PHTHALATE Red YES
1127-05-04411
1127-05-04411
1127-05-04411
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin Electro-Tin Brass DIALLYL PHTHALATE Brown YES
1127-05-04410
1127-05-04410
1127-05-04410
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin Electro-Tin Brass DIALLYL PHTHALATE Black YES
1155-05-0111
1155-05-0111
1155-05-0111
0.265" 0.040 - Press Fit 1/16 0.086 Brass Silver - - PTFE Brown NO
1160-05-0312
1160-05-0312
1160-05-0312
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Gold - - PTFE Red NO
1151-05-0414
1151-05-0414
1151-05-0414
0.350" - - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Yellow NO
1151-05-0419
1151-05-0419
1151-05-0419
0.350" - - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1131-05-0419
1131-05-0419
1131-05-0419
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE White YES
1113-05-0316
1113-05-0316
1113-05-0316
0.460" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
1160-05-0514
1160-05-0514
1160-05-0514
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1131-05-0415
1131-05-0415
1131-05-0415
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE Green YES
1108-05-0516
1108-05-0516
1108-05-0516
0.819" - Double Turret/Double Turret Press Fit Up to 3/16 0.136 Brass Electro Solder - - PTFE Blue NO
