Commercial
Insulated
Pin Terminals

Filter
1102-45-0318
1102-45-0318
1102-45-0318
0.556" - - Press Fit 1/8 0.152 Brass Gold - - PTFE Gray NO
1110-45-0118
1110-45-0118
1110-45-0118
2.500" 0.040 Pin/Pin Press Fit 1/16 0.156 Brass Silver - - PTFE Gray NO
1100-45-0411
1100-45-0411
1100-45-0411
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Electro-Tin - - PTFE Brown NO
1125-45-0312
1125-45-0312
1125-45-0312
0.890" - - 6-32 Nut 1/8 0.144 Brass Gold ZINC Brass PTFE Red NO
1100-45-0412
1100-45-0412
1100-45-0412
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Electro-Tin - - PTFE Red NO
1100-45-0414
1100-45-0414
1100-45-0414
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Electro-Tin - - PTFE Yellow NO
1100-45-0415
1100-45-0415
1100-45-0415
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Electro-Tin - - PTFE Green YES
1110-45-0115
1110-45-0115
1110-45-0115
2.500" 0.040 Pin/Pin Press Fit 1/16 0.156 Brass Silver - - PTFE Green YES
1110-45-0112
1110-45-0112
1110-45-0112
2.500" 0.040 Pin/Pin Press Fit 1/16 0.156 Brass Silver - - PTFE Red NO
1110-45-0111
1110-45-0111
1110-45-0111
2.500" 0.040 Pin/Pin Press Fit 1/16 0.156 Brass Silver - - PTFE Brown NO
1100-45-0119
1100-45-0119
1100-45-0119
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Silver - - PTFE White YES
1100-45-0118
1100-45-0118
1100-45-0118
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Silver - - PTFE Gray NO
1110-45-08810
1110-45-08810
1110-45-08810
2.500" 0.040 Pin/Pin Press Fit 1/16 0.156 Brass Bright Tin-Lead - - PTFE Black NO
1100-45-0315
1100-45-0315
1100-45-0315
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Gold - - PTFE Green YES
1175-444-0416
1175-444-0416
1175-444-0416
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Blue YES
1175-444-04418
1175-444-04418
1175-444-04418
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Gray NO
1175-444-0413
1175-444-0413
1175-444-0413
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Orange NO
1121-10-0511
1121-10-0511
1121-10-0511
0.640" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Brown NO
1121-10-0514
1121-10-0514
1121-10-0514
0.640" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Yellow NO
1121-10-0516
1121-10-0516
1121-10-0516
0.640" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Blue NO
