Commercial
Insulated
Pin Terminals

Filter
1110-39-0510
1110-39-0510
1110-39-0510
0.515" 0.040 Pin/Pin Press Fit 1/16 0.144 Brass Electro Solder - - PTFE Black NO
1110-39-0410
1110-39-0410
1110-39-0410
0.515" 0.040 Pin/Pin Press Fit 1/16 0.144 Brass Electro-Tin - - PTFE Black YES
1110-39-04416
1110-39-04416
1110-39-04416
0.515" 0.040 Pin/Pin Press Fit 1/16 0.144 Brass Bright Tin - - PTFE Blue YES
1127-39-0117
1127-39-0117
1127-39-0117
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Violet YES
1151-39-0114
1151-39-0114
1151-39-0114
0.525" - - Press Fit 1/8 0.158 Brass Silver - - PTFE Yellow NO
1127-39-08818
1127-39-08818
1127-39-08818
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Gray NO
1127-39-0116
1127-39-0116
1127-39-0116
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Blue YES
1127-39-0115
1127-39-0115
1127-39-0115
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Green YES
1110-39-04417
1110-39-04417
1110-39-04417
0.515" 0.040 Pin/Pin Press Fit 1/16 0.144 Brass Bright Tin - - PTFE Violet YES
1125-39-08819
1125-39-08819
1125-39-08819
0.850" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Electro-Tin Brass PTFE White NO
1127-39-0412
1127-39-0412
1127-39-0412
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Red YES
1127-39-0313
1127-39-0313
1127-39-0313
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE Orange YES
1127-39-0515
1127-39-0515
1127-39-0515
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Green NO
1125-39-08814
1125-39-08814
1125-39-08814
0.850" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Electro-Tin Brass PTFE Yellow NO
1127-39-08816
1127-39-08816
1127-39-08816
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Blue NO
1127-39-0112
1127-39-0112
1127-39-0112
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Red YES
1110-39-0315
1110-39-0315
1110-39-0315
0.515" 0.040 Pin/Pin Press Fit 1/16 0.144 Brass Gold - - PTFE Green YES
1126-39-0115
1126-39-0115
1126-39-0115
1.469" - - 6-32 Nut 1/8 0.144 Brass Silver ZINC Brass PTFE Green YES
1110-39-0417
1110-39-0417
1110-39-0417
0.515" 0.040 Pin/Pin Press Fit 1/16 0.144 Brass Electro-Tin - - PTFE Violet YES
1127-39-08812
1127-39-08812
1127-39-08812
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Red NO
