Commercial
Insulated
Pin Terminals

Filter
1129-03-04413
1129-03-04413
1129-03-04413
2.000" 0.030 TURRET/PIN Press Fit 1/8 0.172 Brass Bright Tin - - PTFE Orange NO
1153-32-04412
1153-32-04412
1153-32-04412
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Red NO
1101-05-04416
1101-05-04416
1101-05-04416
0.428" - - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Blue YES
1123-72-04411
1123-72-04411
1123-72-04411
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Brown NO
1102-11-0514
1102-11-0514
1102-11-0514
0.296" - - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1100-18-0112
1100-18-0112
1100-18-0112
0.247" 0.040 - Press Fit 1/32 0.136 Brass Silver - - PTFE Red NO
1102-58-04411
1102-58-04411
1102-58-04411
0.405" - - Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Brown NO
1135-01-04418
1135-01-04418
1135-01-04418
0.510" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Bright Tin - - PTFE Gray NO
1135-01-0417
1135-01-0417
1135-01-0417
0.510" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Electro-Tin - - PTFE Violet YES
1112-19-08813
1112-19-08813
1112-19-08813
0.273" - - Press Fit 1/32 0.205 Brass Bright Tin-Lead - - PTFE Orange NO
1121-27-0419
1121-27-0419
1121-27-0419
1.365" 0.050 Turret/Tip Press Fit 15/32 0.205 Brass Electro-Tin - - PTFE White YES
1115-07-0415
1115-07-0415
1115-07-0415
0.287" 0.060 - Press Fit 1/16 0.205 Brass Electro-Tin - - PTFE Green YES
1153-32-08818
1153-32-08818
1153-32-08818
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Gray NO
1102R-96-0310
1102R-96-0310
1102R-96-0310
0.280" - - Press Fit 1/16 0.086 Brass Gold - - PTFE Black YES
1151-01-08817
1151-01-08817
1151-01-08817
0.280" - - Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Violet NO
1152-02-0113
1152-02-0113
1152-02-0113
0.375" 0.040 - Press Fit 3/32 0.136 Brass Silver - - PTFE Orange NO
1152-02-04411
1152-02-04411
1152-02-04411
0.375" 0.040 - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Brown NO
1151-05-04417
1151-05-04417
1151-05-04417
0.350" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Violet YES
1125-03-04415
1125-03-04415
1125-03-04415
0.485" - - 4-40 1/8 4-40 THREAD Brass Bright Tin Electro-Tin Brass PTFE Green YES
1157-01-0116
1157-01-0116
1157-01-0116
0.350" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Silver - - PTFE Blue YES
