Commercial
Insulated
Pin Terminals

Filter
1131-07-08812
1131-07-08812
1131-07-08812
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Red NO
1131-07-08815
1131-07-08815
1131-07-08815
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Green NO
1131-07-08817
1131-07-08817
1131-07-08817
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Violet NO
1131-07-08818
1131-07-08818
1131-07-08818
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Gray NO
1131-07-08819
1131-07-08819
1131-07-08819
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE White NO
1107-07-08814
1107-07-08814
1107-07-08814
0.587" 0.040 Pin/Pin Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Yellow NO
1107-07-08813
1107-07-08813
1107-07-08813
0.587" 0.040 Pin/Pin Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1123-07-08813
1123-07-08813
1123-07-08813
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1123-07-08811
1123-07-08811
1123-07-08811
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1154R-07-08810
1154R-07-08810
1154R-07-08810
0.478" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1157-07-08811
1157-07-08811
1157-07-08811
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1157-07-08812
1157-07-08812
1157-07-08812
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Bright Tin-Lead - - PTFE Red NO
1157-07-08817
1157-07-08817
1157-07-08817
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Bright Tin-Lead - - PTFE Violet NO
1157-07-08818
1157-07-08818
1157-07-08818
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Bright Tin-Lead - - PTFE Gray NO
1107-07-08810
1107-07-08810
1107-07-08810
0.587" 0.040 Pin/Pin Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1121-07-08817
1121-07-08817
1121-07-08817
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1110-07-04416
1110-07-04416
1110-07-04416
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Blue YES
1110-07-04410
1110-07-04410
1110-07-04410
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Black YES
1156-07-08810
1156-07-08810
1156-07-08810
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Black NO
1156-07-08811
1156-07-08811
1156-07-08811
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Brown NO
