Commercial
Insulated
Pin Terminals

Filter
09-2128-1-04412
09-2128-1-04412
09-2128-1-04412
0.443" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Red NO
09-2128-1-04410
09-2128-1-04410
09-2128-1-04410
0.443" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Black YES
09-2117-1-04411
09-2117-1-04411
09-2117-1-04411
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin Nickel Brass PTFE Brown NO
09-2117-1-04414
09-2117-1-04414
09-2117-1-04414
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin Nickel Brass PTFE Yellow NO
09-2117-1-04418
09-2117-1-04418
09-2117-1-04418
0.878" - Double Turret/Double Turret 6-32 Nut 1/8 0.144 Brass Bright Tin Nickel Brass PTFE Gray NO
09-2095-1-08811
09-2095-1-08811
09-2095-1-08811
0.636" 0.060 ± 0.010 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Brown NO
09-2095-1-08812
09-2095-1-08812
09-2095-1-08812
0.636" 0.060 ± 0.010 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1127-37-0118
1127-37-0118
1127-37-0118
0.828" - - Swage Mount 3/16 0.147 Brass Silver ZINC Brass DIALLYL PHTHALATE Gray YES
1127-37-08813
1127-37-08813
1127-37-08813
0.828" - - Swage Mount 3/16 0.147 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Orange NO
1127-37-08815
1127-37-08815
1127-37-08815
0.828" - - Swage Mount 3/16 0.147 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Green NO
1110-37-0417
1110-37-0417
1110-37-0417
0.890" 0.045 Pin/Pin Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Violet YES
1110-37-0419
1110-37-0419
1110-37-0419
0.890" 0.045 Pin/Pin Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1127-37-0119
1127-37-0119
1127-37-0119
0.828" - - Swage Mount 3/16 0.147 Brass Silver ZINC Brass DIALLYL PHTHALATE White YES
1127-37-08812
1127-37-08812
1127-37-08812
0.828" - - Swage Mount 3/16 0.147 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Red NO
1100-37-0317
1100-37-0317
1100-37-0317
0.460" 0.040 - Press Fit 1/16 0.136 Brass Gold - - PTFE Violet YES
1110-37-08810
1110-37-08810
1110-37-08810
0.890" 0.045 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Black NO
1111-37-08817
1111-37-08817
1111-37-08817
0.500" 0.053 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1111-37-04418
1111-37-04418
1111-37-04418
0.500" 0.053 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Gray NO
1111-37-04417
1111-37-04417
1111-37-04417
0.500" 0.053 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Violet YES
1111-37-04411
1111-37-04411
1111-37-04411
0.500" 0.053 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Brown NO
