Commercial
Insulated
Pin Terminals

Filter
1123-04-04414
1123-04-04414
1123-04-04414
0.947" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Yellow NO
1111R-04-0519
1111R-04-0519
1111R-04-0519
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Electro Solder - - PTFE White NO
1113-04-04415
1113-04-04415
1113-04-04415
0.411" - - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Green YES
1110-04-08813
1110-04-08813
1110-04-08813
0.453" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Orange NO
1110-04-08814
1110-04-08814
1110-04-08814
0.453" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Yellow NO
1133-04-0511
1133-04-0511
1133-04-0511
0.531" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Brown NO
1130R-04-0518
1130R-04-0518
1130R-04-0518
0.906" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Gray NO
1114-04-0311
1114-04-0311
1114-04-0311
0.225" 0.040 - Press Fit 1/32 0.086 Brass Gold - - PTFE Brown NO
1111-04-04416
1111-04-04416
1111-04-04416
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Blue YES
1114-04-0312
1114-04-0312
1114-04-0312
0.225" 0.040 - Press Fit 1/32 0.086 Brass Gold - - PTFE Red NO
1121-04-0317
1121-04-0317
1121-04-0317
0.433" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Violet YES
1114-04-0316
1114-04-0316
1114-04-0316
0.225" 0.040 - Press Fit 1/32 0.086 Brass Gold - - PTFE Blue YES
1121-04-0517
1121-04-0517
1121-04-0517
0.433" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Violet NO
1110-04-08817
1110-04-08817
1110-04-08817
0.453" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Violet NO
1131-04-08815
1131-04-08815
1131-04-08815
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Green NO
1104-04-04416
1104-04-04416
1104-04-04416
0.392" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Blue YES
1104-04-0516
1104-04-0516
1104-04-0516
0.392" - - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Blue NO
1156-04-0110
1156-04-0110
1156-04-0110
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Silver - - PTFE Black YES
1121-04-0312
1121-04-0312
1121-04-0312
0.433" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Red NO
1111-04-04412
1111-04-04412
1111-04-04412
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Red NO
