Commercial
Insulated
Pin Terminals

Filter
1130R-07-0516
1130R-07-0516
1130R-07-0516
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Blue NO
1130R-07-0515
1130R-07-0515
1130R-07-0515
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Green NO
1115-07-08810
1115-07-08810
1115-07-08810
0.287" 0.060 - Press Fit 1/16 0.205 Brass Bright Tin-Lead - - PTFE Black NO
1108-07-04414
1108-07-04414
1108-07-04414
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Bright Tin - - PTFE Yellow NO
1115-07-08818
1115-07-08818
1115-07-08818
0.287" 0.060 - Press Fit 1/16 0.205 Brass Bright Tin-Lead - - PTFE Gray NO
1108-07-0517
1108-07-0517
1108-07-0517
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Electro Solder - - PTFE Violet NO
1108-07-0118
1108-07-0118
1108-07-0118
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Silver - - PTFE Gray NO
1108-07-0518
1108-07-0518
1108-07-0518
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Electro Solder - - PTFE Gray NO
1123-07-08814
1123-07-08814
1123-07-08814
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Yellow NO
1111-07-0416
1111-07-0416
1111-07-0416
0.438" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Blue YES
1135-07-0310
1135-07-0310
1135-07-0310
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Gold - - PTFE Black YES
1135-07-0513
1135-07-0513
1135-07-0513
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Orange NO
1130-07-0112
1130-07-0112
1130-07-0112
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Silver - - PTFE Red NO
1108-07-04413
1108-07-04413
1108-07-04413
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Bright Tin - - PTFE Orange NO
1130-07-0119
1130-07-0119
1130-07-0119
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Silver - - PTFE White YES
1130-07-0115
1130-07-0115
1130-07-0115
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Silver - - PTFE Green YES
1112-07-0313
1112-07-0313
1112-07-0313
0.273" - - Press Fit 1/16 0.113 Brass Gold - - PTFE Orange NO
1112-07-0315
1112-07-0315
1112-07-0315
0.273" - - Press Fit 1/16 0.113 Brass Gold - - PTFE Green YES
1123-07-08816
1123-07-08816
1123-07-08816
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1131-07-0317
1131-07-0317
1131-07-0317
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Violet YES
