Commercial
Insulated
Pin Terminals

Filter
1111-52-0117
1111-52-0117
1111-52-0117
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 3/16 0.205 Brass Silver - - PTFE Violet YES
1154-51-0111
1154-51-0111
1154-51-0111
0.731" - DOUBLE TURRET/SLOTTED Press Fit Up to 3/16 0.205 Brass Silver - - PTFE Brown NO
1127-50-08812
1127-50-08812
1127-50-08812
0.813" - - Swage Mount 1/16 0.147 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Red NO
1123-50-08813
1123-50-08813
1123-50-08813
0.593" - TURRET/SLOTTED Press Fit 1/16 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1175-483-0118
1175-483-0118
1175-483-0118
0.741" - DOUBLE Turret/Turret PRESS LOCK 3/32 0.188 (+0.003/-0.001) Brass Silver - - PTFE Gray NO
1175-482-0518
1175-482-0518
1175-482-0518
0.709" - DOUBLE Turret/Turret PRESS LOCK 1/16 0.188 (+0.003/-0.001) Brass Electro Solder - - PTFE Gray NO
1127-48-04416
1127-48-04416
1127-48-04416
0.875" - - Swage Mount 1/8 0.104 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1175-471-08811
1175-471-08811
1175-471-08811
0.512" - - PRESS LOCK 1/32 0.188 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Brown NO
1110-47-08810
1110-47-08810
1110-47-08810
0.865" 0.050 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1127-47-0319
1127-47-0319
1127-47-0319
0.844" - - Swage Mount 3/32 0.104 Brass Gold ZINC Brass DIALLYL PHTHALATE White YES
1175-461-08818
1175-461-08818
1175-461-08818
0.361" - - PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Gray NO
1110-46-08811
1110-46-08811
1110-46-08811
0.740" 0.063 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1175-421-0116
1175-421-0116
1175-421-0116
0.662" - Double Turret/Double Turret PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Blue YES
1125-91-0112
1125-91-0112
1125-91-0112
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver Electro-Tin Brass PTFE Red NO
1110-36-08814
1110-36-08814
1110-36-08814
0.585" 0.045 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1111-32-04411
1111-32-04411
1111-32-04411
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.162 Brass Bright Tin - - PTFE Brown NO
1111-31-04418
1111-31-04418
1111-31-04418
1.337" 0.050 DOUBLE Turret/Tip Press Fit 11/32 0.158 Brass Bright Tin - - PTFE Gray NO
1127-30-0510
1127-30-0510
1127-30-0510
0.813" - - 4-40 Nut 3/32 0.120 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Black NO
1110-28-08815
1110-28-08815
1110-28-08815
0.562" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1121-28-0516
1121-28-0516
1121-28-0516
0.718" 0.046 Turret/Tip Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Blue NO
