Commercial
Insulated
Pin Terminals

Filter
1111-09-04412
1111-09-04412
1111-09-04412
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Red NO
1100-09-0318
1100-09-0318
1100-09-0318
0.350" 0.040 - Press Fit 3/32 0.098 Brass Gold - - PTFE Gray NO
1127-09-08812
1127-09-08812
1127-09-08812
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Red NO
1114R-09-0312
1114R-09-0312
1114R-09-0312
0.193" 0.050 - Press Fit 1/32 0.113 Brass Gold - - PTFE Red NO
1111-09-04414
1111-09-04414
1111-09-04414
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Yellow NO
1111-09-04417
1111-09-04417
1111-09-04417
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Violet YES
1111-09-04418
1111-09-04418
1111-09-04418
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Gray NO
1111-09-04419
1111-09-04419
1111-09-04419
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE White YES
1100R-09-08818
1100R-09-08818
1100R-09-08818
0.350" 0.040 - Press Fit 3/32 0.098 Brass Bright Tin-Lead - - PTFE Gray NO
1131-09-0514
1131-09-0514
1131-09-0514
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1131-09-0512
1131-09-0512
1131-09-0512
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Red NO
1127-09-0516
1127-09-0516
1127-09-0516
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Blue NO
1127-09-0517
1127-09-0517
1127-09-0517
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Violet NO
1114R-09-0315
1114R-09-0315
1114R-09-0315
0.193" 0.050 - Press Fit 1/32 0.113 Brass Gold - - PTFE Green YES
1123-09-0512
1123-09-0512
1123-09-0512
1.197" 0.050 TIP/SLOTTED Press Fit 1/2 0.158 Brass Electro Solder - - PTFE Red NO
1127-09-0518
1127-09-0518
1127-09-0518
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Gray NO
1110-09-0317
1110-09-0317
1110-09-0317
0.375" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Gold - - PTFE Violet YES
1127-09-0519
1127-09-0519
1127-09-0519
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE White NO
1125-09-0114
1125-09-0114
1125-09-0114
0.516" - - Swage Mount 1/8 0.116 ±0.002 Brass Silver Electro-Tin Brass PTFE Yellow NO
1125-09-0111
1125-09-0111
1125-09-0111
0.516" - - Swage Mount 1/8 0.116 ±0.002 Brass Silver Electro-Tin Brass PTFE Brown NO
