Commercial
Insulated
Pin Terminals

Filter
1110-55-08813
1110-55-08813
1110-55-08813
0.515" 0.040 Pin/Pin Press Fit 1/16 0.166 Brass Bright Tin-Lead - - PTFE Orange NO
1135-05-0415
1135-05-0415
1135-05-0415
0.552" 0.030 (+0.000/-0.005) Pin/Slotted Press Fit 1/16 0.070 Brass Electro-Tin - - PTFE Green YES
1152R-01-0413
1152R-01-0413
1152R-01-0413
0.350" 0.040 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1152R-01-0412
1152R-01-0412
1152R-01-0412
0.350" 0.040 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Red NO
1118-01-0114
1118-01-0114
1118-01-0114
0.312" 0.040 Pin/Pin Press Fit 1/16 0.093 Brass Silver - - PTFE Yellow NO
1155-01-0312
1155-01-0312
1155-01-0312
0.427" - - Press Fit Up to 3/16 0.204 Brass Gold - - PTFE Red NO
1118-01-0113
1118-01-0113
1118-01-0113
0.312" 0.040 Pin/Pin Press Fit 1/16 0.093 Brass Silver - - PTFE Orange NO
1133-01-0115
1133-01-0115
1133-01-0115
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Silver - - PTFE Green YES
1131-01-04412
1131-01-04412
1131-01-04412
0.687" 0.040 Pin/Tip Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Red NO
1137-01-0317
1137-01-0317
1137-01-0317
0.510" 0.030 (+0.000/-0.005) Pin/Slotted Press Fit 1/16 0.070 Brass Gold - - PTFE Violet YES
1123-01-0311
1123-01-0311
1123-01-0311
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Brown NO
1151-01-0411
1151-01-0411
1151-01-0411
0.280" - - Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Brown NO
1131-01-04413
1131-01-04413
1131-01-04413
0.687" 0.040 Pin/Tip Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Orange NO
1105-01-0116
1105-01-0116
1105-01-0116
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Silver - - PTFE Blue YES
1121-01-04413
1121-01-04413
1121-01-04413
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Orange NO
1101R-01-08815
1101R-01-08815
1101R-01-08815
0.328" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1103-01-0119
1103-01-0119
1103-01-0119
0.250" - - Press Fit 1/16 0.136 Brass Silver - - PTFE White YES
1113-01-04410
1113-01-04410
1113-01-04410
0.303" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Black YES
1113-01-04412
1113-01-04412
1113-01-04412
0.303" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Red NO
1121-01-04418
1121-01-04418
1121-01-04418
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Gray NO
