Commercial
Insulated
Pin Terminals

Filter
1169-08-08814
1169-08-08814
1169-08-08814
0.499" - - 2-56 Nut 1/32 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Yellow NO
1156-08-0116
1156-08-0116
1156-08-0116
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Silver - - PTFE Blue YES
1156-08-0115
1156-08-0115
1156-08-0115
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Silver - - PTFE Green YES
1111-08-0517
1111-08-0517
1111-08-0517
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Violet NO
1111-08-0518
1111-08-0518
1111-08-0518
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Gray NO
1107-08-0518
1107-08-0518
1107-08-0518
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Gray NO
1169-08-08813
1169-08-08813
1169-08-08813
0.499" - - 2-56 Nut 1/32 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Orange NO
1169-08-08812
1169-08-08812
1169-08-08812
0.499" - - 2-56 Nut 1/32 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Red NO
1169-08-08811
1169-08-08811
1169-08-08811
0.499" - - 2-56 Nut 1/32 0.094 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Brown NO
1127-08-04413
1127-08-04413
1127-08-04413
0.884" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Orange YES
1107-08-0517
1107-08-0517
1107-08-0517
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Violet NO
1107-08-0515
1107-08-0515
1107-08-0515
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Green NO
1110-08-04419
1110-08-04419
1110-08-04419
0.335" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE White YES
1110-08-04417
1110-08-04417
1110-08-04417
0.335" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Violet YES
1110-08-04416
1110-08-04416
1110-08-04416
0.335" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Blue YES
1110-08-04413
1110-08-04413
1110-08-04413
0.335" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Orange NO
1110-08-04411
1110-08-04411
1110-08-04411
0.335" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Brown NO
1113R-08-04417
1113R-08-04417
1113R-08-04417
0.333" - - Press Fit 1/6 0.136 Brass Bright Tin - - PTFE Violet YES
1107-08-0110
1107-08-0110
1107-08-0110
0.696" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Silver - - PTFE Black YES
1114-08-08816
1114-08-08816
1114-08-08816
0.310" 0.040 - Press Fit 3/32 0.108 Brass Bright Tin-Lead - - PTFE Blue NO
