Commercial
Insulated
Pin Terminals

Filter
1151-21-08812
1151-21-08812
1151-21-08812
0.509" - - Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1111-32-08811
1111-32-08811
1111-32-08811
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.162 Brass Bright Tin-Lead - - PTFE Brown NO
1111-32-08810
1111-32-08810
1111-32-08810
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.162 Brass Bright Tin-Lead - - PTFE Black NO
1169-32-0516
1169-32-0516
1169-32-0516
0.797" - - 2-56 Nut 1/16 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Blue NO
1110-32-04411
1110-32-04411
1110-32-04411
0.710" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Bright Tin - - PTFE Brown NO
1169-32-0512
1169-32-0512
1169-32-0512
0.797" - - 2-56 Nut 1/16 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Red NO
1169-32-0510
1169-32-0510
1169-32-0510
0.797" - - 2-56 Nut 1/16 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Black NO
1125-32-08812
1125-32-08812
1125-32-08812
0.630" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Red NO
1125-32-08815
1125-32-08815
1125-32-08815
0.630" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Green NO
1169-32-04419
1169-32-04419
1169-32-04419
0.797" - - 2-56 Nut 1/16 0.094 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE White YES
1110-32-04417
1110-32-04417
1110-32-04417
0.710" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Bright Tin - - PTFE Violet YES
1177-32-0311
1177-32-0311
1177-32-0311
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Gold - - PTFE Brown NO
1110-32-04419
1110-32-04419
1110-32-04419
0.710" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Bright Tin - - PTFE White YES
1121-32-08810
1121-32-08810
1121-32-08810
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Bright Tin-Lead - - PTFE Black NO
1177-32-0316
1177-32-0316
1177-32-0316
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Gold - - PTFE Blue YES
1169-32-04417
1169-32-04417
1169-32-04417
0.797" - - 2-56 Nut 1/16 0.094 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Violet YES
1169-32-04415
1169-32-04415
1169-32-04415
0.797" - - 2-56 Nut 1/16 0.094 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Green YES
1169-32-04411
1169-32-04411
1169-32-04411
0.797" - - 2-56 Nut 1/16 0.094 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Brown YES
1126-32-0411
1126-32-0411
1126-32-0411
1.172" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Electro-Tin ZINC Brass PTFE Brown NO
1125-32-0111
1125-32-0111
1125-32-0111
0.630" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver Electro-Tin Brass PTFE Brown NO
