Commercial
Insulated
Pin Terminals

Filter
1153-06-0111
1153-06-0111
1153-06-0111
0.515" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Silver - - PTFE Brown NO
1151R-06-0110
1151R-06-0110
1151R-06-0110
0.375" - - Press Fit 3/32 0.136 Brass Silver - - PTFE Black YES
1157-06-08813
1157-06-08813
1157-06-08813
1.115" 0.050 TURRET/PIN Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1107-06-0311
1107-06-0311
1107-06-0311
0.572" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Brown NO
1156R-06-0416
1156R-06-0416
1156R-06-0416
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Blue YES
1130R-05-0514
1130R-05-0514
1130R-05-0514
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Yellow NO
1160-05-04415
1160-05-04415
1160-05-04415
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Green YES
1160-05-0318
1160-05-0318
1160-05-0318
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Gold - - PTFE Gray NO
1160-05-04416
1160-05-04416
1160-05-04416
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Blue YES
1131-05-0416
1131-05-0416
1131-05-0416
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE Blue YES
1112-05-04419
1112-05-04419
1112-05-04419
0.200" - - Press Fit 1/32 0.113 Brass Bright Tin - - PTFE White YES
1112-05-04418
1112-05-04418
1112-05-04418
0.200" - - Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Gray NO
1112-05-04416
1112-05-04416
1112-05-04416
0.200" - - Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Blue YES
1110-05-04419
1110-05-04419
1110-05-04419
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE White YES
1155-05-0512
1155-05-0512
1155-05-0512
0.265" 0.040 - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Red NO
1110-05-04418
1110-05-04418
1110-05-04418
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Gray NO
1106-05-0412
1106-05-0412
1106-05-0412
0.540" - - Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Red NO
1130-05-04419
1130-05-04419
1130-05-04419
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Bright Tin - - PTFE White YES
1170-05-07514
1170-05-07514
1170-05-07514
0.844" - - 4-40 Nut 3/32 0.120 Brass ZINC ZINC Brass DIALLYL PHTHALATE Yellow YES
1160-05-04418
1160-05-04418
1160-05-04418
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Gray NO
