Commercial
Insulated
Pin Terminals

Filter
1106-50-0517
1106-50-0517
1106-50-0517
0.350" - - Press Fit 1/16 0.091 Brass Electro Solder - - PTFE Violet NO
1100-14-04418
1100-14-04418
1100-14-04418
0.280" 0.040 - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Gray NO
1111-41-04418
1111-41-04418
1111-41-04418
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 3/16 0.172 Brass Bright Tin - - PTFE Gray NO
1151-01-04418
1151-01-04418
1151-01-04418
0.280" - - Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Gray NO
1111-41-0410
1111-41-0410
1111-41-0410
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 3/16 0.172 Brass Electro-Tin - - PTFE Black YES
1131-04-0516
1131-04-0516
1131-04-0516
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Blue NO
1102-46-0514
1102-46-0514
1102-46-0514
0.556" - - Press Fit 1/16 0.152 Brass Electro Solder - - PTFE Yellow NO
1156-17-0516
1156-17-0516
1156-17-0516
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.158 Brass Electro Solder - - PTFE Blue NO
1110-53-04415
1110-53-04415
1110-53-04415
0.437" 0.050 TURRET/PIN Press Fit 3/32 0.172 Brass Bright Tin - - PTFE Green YES
1154-08-08813
1154-08-08813
1154-08-08813
0.540" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Orange NO
1154-08-08812
1154-08-08812
1154-08-08812
0.540" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Red NO
1157-06-04416
1157-06-04416
1157-06-04416
1.115" 0.050 TURRET/PIN Press Fit 11/32 0.158 Brass Bright Tin - - PTFE Blue YES
1177-33-0316
1177-33-0316
1177-33-0316
0.530" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Gold - - PTFE Blue YES
1114-75-0518
1114-75-0518
1114-75-0518
0.367" - - Press Fit 1/16 0.158 Brass Electro Solder - - PTFE Gray NO
1137-03-0517
1137-03-0517
1137-03-0517
0.320" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Violet NO
1125-35-08812
1125-35-08812
1125-35-08812
0.850" - - 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead Electro-Tin Brass PTFE Red NO
1125-02-0315
1125-02-0315
1125-02-0315
0.578" - - 2-56 Nut 7/64 0.094 Brass Gold Electro-Tin Brass PTFE Green YES
1125-39-0414
1125-39-0414
1125-39-0414
0.850" - - 4-40 Nut 1/8 0.120 Brass Electro-Tin Electro-Tin Brass PTFE Yellow NO
1125-18-04415
1125-18-04415
1125-18-04415
0.760" - - 6-32 Nut 1/8 0.144 Brass Bright Tin Electro-Tin Brass PTFE Green YES
1115-51-0515
1115-51-0515
1115-51-0515
0.453" - - Press Fit 1/16 0.187 Brass Electro Solder - - PTFE Green NO
