Commercial
Insulated
Pin Terminals

Filter
1175-471-0514
1175-471-0514
1175-471-0514
0.512" - - PRESS LOCK 1/32 0.188 (+0.003/-0.001) Brass Electro Solder - - PTFE Yellow NO
1175-471-0315
1175-471-0315
1175-471-0315
0.512" - - PRESS LOCK 1/32 0.188 (+0.003/-0.001) Brass Gold - - PTFE Green YES
1175-471-04412
1175-471-04412
1175-471-04412
0.512" - - PRESS LOCK 1/32 0.188 (+0.003/-0.001) Brass Bright Tin - - PTFE Red NO
1111-47-0517
1111-47-0517
1111-47-0517
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.221 Brass Electro Solder - - PTFE Violet NO
1125-60-0111
1125-60-0111
1125-60-0111
1.297" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass PTFE Brown NO
1100-47-0519
1100-47-0519
1100-47-0519
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE White NO
1100-47-0518
1100-47-0518
1100-47-0518
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE Gray NO
1100-47-0516
1100-47-0516
1100-47-0516
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE Blue NO
1100-47-0515
1100-47-0515
1100-47-0515
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE Green NO
1100-47-0513
1100-47-0513
1100-47-0513
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE Orange NO
1100-47-0511
1100-47-0511
1100-47-0511
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro Solder - - PTFE Brown NO
1100-47-0415
1100-47-0415
1100-47-0415
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro-Tin - - PTFE Green YES
1102-47-08815
1102-47-08815
1102-47-08815
0.618" - - Press Fit 1/8 0.152 Brass Bright Tin-Lead - - PTFE Green NO
1102-47-08813
1102-47-08813
1102-47-08813
0.618" - - Press Fit 1/8 0.152 Brass Bright Tin-Lead - - PTFE Orange NO
1111-47-0315
1111-47-0315
1111-47-0315
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.221 Brass Gold - - PTFE Green YES
1100-47-0412
1100-47-0412
1100-47-0412
0.350" 0.040 - Press Fit 1/16 0.166 Brass Electro-Tin - - PTFE Red NO
1110-47-04418
1110-47-04418
1110-47-04418
0.865" 0.050 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Gray NO
1100-47-08817
1100-47-08817
1100-47-08817
0.350" 0.040 - Press Fit 1/16 0.166 Brass Bright Tin-Lead - - PTFE Violet NO
1127-47-0518
1127-47-0518
1127-47-0518
0.844" - - Swage Mount 3/32 0.104 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Gray NO
1102-47-0112
1102-47-0112
1102-47-0112
0.618" - - Press Fit 1/8 0.152 Brass Silver - - PTFE Red NO
