Commercial
Insulated
Pin Terminals

Filter
1107-01-0519
1107-01-0519
1107-01-0519
0.600" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro Solder - - PTFE White NO
1130-01-08813
1130-01-08813
1130-01-08813
1.937" (0.030)/(0.050) Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1130-01-08814
1130-01-08814
1130-01-08814
1.937" (0.030)/(0.050) Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1113-01-0411
1113-01-0411
1113-01-0411
0.303" - - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Brown NO
1130-01-08818
1130-01-08818
1130-01-08818
1.937" (0.030)/(0.050) Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
1101-01-08816
1101-01-08816
1101-01-08816
0.328" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1101-01-08813
1101-01-08813
1101-01-08813
0.328" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1101-01-08810
1101-01-08810
1101-01-08810
0.328" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Black NO
1124-01-08816
1124-01-08816
1124-01-08816
0.899" 0.050 THREAD/TIP Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1124-01-08819
1124-01-08819
1124-01-08819
0.899" 0.050 THREAD/TIP Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE White NO
1139-01-0419
1139-01-0419
1139-01-0419
0.248" 0.017 Pin/Pin Press Fit 1/64 0.049 Brass Electro-Tin - - PTFE White YES
1155-01-0514
1155-01-0514
1155-01-0514
0.427" - - Press Fit Up to 3/16 0.204 Brass Electro Solder - - PTFE Yellow NO
1120-01-0513
1120-01-0513
1120-01-0513
0.833" 0.050 Pin/Hook Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Orange NO
1113-01-0315
1113-01-0315
1113-01-0315
0.303" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Green YES
1107-01-0412
1107-01-0412
1107-01-0412
0.600" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Red NO
1107-01-0413
1107-01-0413
1107-01-0413
0.600" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1107-01-0415
1107-01-0415
1107-01-0415
0.600" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Green YES
1107-01-0416
1107-01-0416
1107-01-0416
0.600" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Blue YES
1107-01-0417
1107-01-0417
1107-01-0417
0.600" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Violet YES
1103-01-0419
1103-01-0419
1103-01-0419
0.250" - - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
