Commercial
Insulated
Pin Terminals

Filter
1153-07-0512
1153-07-0512
1153-07-0512
0.540" 0.040 Pin/Pin Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Red NO
1125-07-0317
1125-07-0317
1125-07-0317
0.454" - - Swage Mount 1/16 0.116 ±0.002 Brass Gold Electro-Tin Brass PTFE Violet YES
1125-07-0319
1125-07-0319
1125-07-0319
0.454" - - Swage Mount 1/16 0.116 ±0.002 Brass Gold Electro-Tin Brass PTFE White YES
1153-07-0510
1153-07-0510
1153-07-0510
0.540" 0.040 Pin/Pin Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Black NO
1131-07-0313
1131-07-0313
1131-07-0313
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Orange NO
1113R-07-08818
1113R-07-08818
1113R-07-08818
0.333" - - Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
1121R-07-08814
1121R-07-08814
1121R-07-08814
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1123R-07-0310
1123R-07-0310
1123R-07-0310
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Gold - - PTFE Black YES
1130R-07-0419
1130R-07-0419
1130R-07-0419
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro-Tin - - PTFE White YES
1107-07-0411
1107-07-0411
1107-07-0411
0.587" 0.040 Pin/Pin Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Brown NO
1103-01-0312
1103-01-0312
1103-01-0312
0.250" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Red NO
1131-07-08813
1131-07-08813
1131-07-08813
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Orange NO
1131-07-08811
1131-07-08811
1131-07-08811
0.906" (0.040)/(0.050) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Brown NO
1154R-07-0113
1154R-07-0113
1154R-07-0113
0.478" - - Press Fit 1/8 0.158 Brass Silver - - PTFE Orange NO
1125-01-0316
1125-01-0316
1125-01-0316
0.485" - - 2-56 1/8 2-56 THREAD Brass Gold Electro-Tin Brass PTFE Blue YES
1103-07-0416
1103-07-0416
1103-07-0416
0.519" - - Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Blue YES
1157-07-0519
1157-07-0519
1157-07-0519
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Electro Solder - - PTFE White NO
1121R-07-08813
1121R-07-08813
1121R-07-08813
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1115-07-0118
1115-07-0118
1115-07-0118
0.287" 0.060 - Press Fit 1/16 0.205 Brass Silver - - PTFE Gray NO
1127-07-0315
1127-07-0315
1127-07-0315
0.938" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE Green YES
