Insulated
PC Jacks

Filter
09-9011-1-08817
09-9011-1-08817
09-9011-1-08817
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.137 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Violet -
09-9011-1-08818
09-9011-1-08818
09-9011-1-08818
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.137 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Gray -
09-9401-1-03510
09-9401-1-03510
09-9401-1-03510
0.080 0.500 " 0.530" Jack/Pin Press Fit 0.177 1/64 - 1/16 Vertical Brass Gold PTFE Black -
09-9010-1-03510
09-9010-1-03510
09-9010-1-03510
0.040 0.195 " 0.343" Jack/Pin Solder 0.027 1/32 - 1/16 Vertical Brass Gold Polyolefin Black -
1128-02-03517
1128-02-03517
1128-02-03517
0.040 0.205 " 0.410" Jack/Turret Press Fit 0.108 1/32 - 3/16 Vertical - - PTFE Violet -
1128-02-03519
1128-02-03519
1128-02-03519
0.040 0.205 " 0.410" Jack/Turret Press Fit 0.108 1/32 - 3/16 Vertical - - PTFE White -
1128-83-030118
1128-83-030118
1128-83-030118
0.040 0.125 " 0.379" Jack/Turret Press Fit 0.136 1/32 - 3/32 Vertical - - PTFE Gray -
1128-39-0314
1128-39-0314
1128-39-0314
0.040 0.135 " 0.408" Jack/Solder Cup Press Fit 0.136 1/32 - 1/8 Vertical - - PTFE Yellow -
1128-83-030110
1128-83-030110
1128-83-030110
0.040 0.125 " 0.379" Jack/Turret Press Fit 0.136 1/32 - 3/32 Vertical - - PTFE Black -
1128-36-0313
1128-36-0313
1128-36-0313
0.040 0.135 " 0.408" Jack/Pin Press Fit 0.136 1/32 - 1/8 Vertical - - PTFE Orange -
1138-32-03512
1138-32-03512
1138-32-03512
0.080 0.250 " 0.912" Jack/Pin Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE Red -
1128-03-0311
1128-03-0311
1128-03-0311
0.040 0.245 " 0.449" Jack/Turret Press Fit 0.108 1/32 - 15/64 Vertical - - PTFE Brown -
1128-58-0319
1128-58-0319
1128-58-0319
0.080 0.200 " 0.580" Jack/Pin Solder 0.052  1/32 - 3/32 Vertical - - PTFE White -
1128-03-0313
1128-03-0313
1128-03-0313
0.040 0.245 " 0.449" Jack/Turret Press Fit 0.108 1/32 - 15/64 Vertical - - PTFE Orange -
09-9175-1-0314
09-9175-1-0314
09-9175-1-0314
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Gold PTFE Yellow -
1128-03-0315
1128-03-0315
1128-03-0315
0.040 0.245 " 0.449" Jack/Turret Press Fit 0.108 1/32 - 15/64 Vertical - - PTFE Green -
1128-83-030112
1128-83-030112
1128-83-030112
0.040 0.125 " 0.379" Jack/Turret Press Fit 0.136 1/32 - 3/32 Vertical - - PTFE Red -
1128-56-0310
1128-56-0310
1128-56-0310
0.080 0.250 " 0.587" - Press Fit 0.205 1/32 - 17/64 Vertical - - PTFE Black -
09-9221-1-0314
09-9221-1-0314
09-9221-1-0314
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Gold Nylon Yellow -
1138-03-0319
1138-03-0319
1138-03-0319
0.080 0.250 " 0.441" - Swage Mount 0.114 1/32 Vertical - - PTFE White -
