Commercial
Non-Insulated
Terminals

Filter
10-961-3-088
10-961-3-088
10-961-3-088
0.229" - - Swage Mount 0.125" 3/32 0.0635 Brass Bright Tin-Lead NO
09-0112-2-03
09-0112-2-03
09-0112-2-03
0.448" - TURRET/THREAD Swage Mount 0.094" 1/16 0.154 Brass Gold YES
09-8332-2-088
09-8332-2-088
09-8332-2-088
0.270" 0.020 - Solder 0.100" 1/64 TO 1/16 0.0225 Brass Bright Tin-Lead NO
10-513-4-03
10-513-4-03
10-513-4-03
0.484" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.129 Brass Gold YES
10-858-3-088
10-858-3-088
10-858-3-088
0.594" 0.040 Pin/Pin Swage Mount 0.125" 3/32 0.094 Brass Bright Tin-Lead NO
10-525-3-088
10-525-3-088
10-525-3-088
0.551" - Double Turret/Double Turret Swage Mount 0.115" 3/32 0.094 Brass Bright Tin-Lead NO
10-823-4-03
10-823-4-03
10-823-4-03
0.628" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.151" 1/8 0.120 Brass Gold YES
10-823-6-03
10-823-6-03
10-823-6-03
0.691" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.214" 3/16 0.120 Brass Gold YES
10-417-2-088
10-417-2-088
10-417-2-088
0.500" - - Swage Mount 0.109" 1/16 0.116 Brass Bright Tin-Lead NO
10-806-2-088
10-806-2-088
10-806-2-088
0.536" - - Swage Mount 0.109" 1/16 0.094 Brass Bright Tin-Lead NO
10-921-2-088
10-921-2-088
10-921-2-088
0.302" 0.045 - Swage Mount 0.094" 1/16 0.064 Brass Bright Tin-Lead NO
10-454-3-03
10-454-3-03
10-454-3-03
0.375" - - Swage Mount 0.125" 3/32 0.067 Brass Gold YES
10-114-4-088
10-114-4-088
10-114-4-088
0.241" - - Swage Mount 0.147" 1/8 0.043 Brass Bright Tin-Lead NO
10-801-6-03
10-801-6-03
10-801-6-03
0.535" 0.040 TURRET/PIN Swage Mount 0.207" 3/16 0.076 Brass Gold YES
09-8136-3-03
09-8136-3-03
09-8136-3-03
0.479" 0.040 TURRET/PIN Swage Mount 0.125" 3/32 0.125 Brass Gold YES
10-801-3-03
10-801-3-03
10-801-3-03
0.441" 0.040 TURRET/PIN Swage Mount 0.113" 3/32 0.076 Brass Gold YES
10-964-2-088
10-964-2-088
10-964-2-088
0.174" 0.025 - Swage Mount 0.082" 1/16 0.035 Brass Bright Tin-Lead NO
10-803-8-03
10-803-8-03
10-803-8-03
0.645" 0.040 TURRET/PIN Swage Mount 0.270" 1/4 0.076 Brass Gold YES
10-501-1-03
10-501-1-03
10-501-1-03
0.237" - Turret/Turret Swage Mount 0.051" 1/32 0.076 Brass Gold YES
10-554-2-03
10-554-2-03
10-554-2-03
0.427" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.094 Brass Gold YES
