Commercial
Non-Insulated
Terminals

Filter
10-820-4-03
10-820-4-03
10-820-4-03
0.338" 0.040 - Swage Mount 0.165" 1/8 0.094 Brass Gold YES
10-108-2-088
10-108-2-088
10-108-2-088
0.177" - - Swage Mount 0.084" 1/16 0.067 Brass Bright Tin-Lead NO
10-217-1-05
10-217-1-05
10-217-1-05
0.419" - - Swage Mount 0.075" 1/32 0.116 Brass Electro Solder NO
09-0219-2-05
09-0219-2-05
09-0219-2-05
0.395" - - Swage Mount 0.085" 1/16 0.067 Brass Electro Solder NO
10-410-2-05
10-410-2-05
10-410-2-05
0.433" - - Swage Mount 0.105" 1/16 0.116 Brass Electro Solder NO
10-303-2-05
10-303-2-05
10-303-2-05
0.433" - - Swage Mount 0.105" 1/16 0.116 Brass Electro Solder NO
10-602-4-05
10-602-4-05
10-602-4-05
0.656" - - Swage Mount 0.172" 1/8 0.116 Brass Electro Solder NO
10-714-3-05
10-714-3-05
10-714-3-05
0.697" - DOUBLE TURRET/THREAD Swage Mount 0.135" 3/32 0.204 Brass Electro Solder NO
10-903-4-03
10-903-4-03
10-903-4-03
0.344" - - Swage Mount 0.156" 1/8 0.063 Brass Gold YES
10-920-1-044
10-920-1-044
10-920-1-044
0.171" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-905-2-03
10-905-2-03
10-905-2-03
0.282" - - Swage Mount 0.094" 1/16 0.0635 Brass Gold YES
10-8016-3-03
10-8016-3-03
10-8016-3-03
0.643" 0.080 - Swage Mount 0.113" 3/32 0.094 Brass Gold YES
10-302-2-05
10-302-2-05
10-302-2-05
0.240" - - Swage Mount 0.084" 1/16 0.067 Brass Electro Solder NO
09-8076-2-05
09-8076-2-05
09-8076-2-05
0.782" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
09-8343-2-04
09-8343-2-04
09-8343-2-04
0.282" - - Swage Mount 0.094" 1/16 0.067 Brass Electro-Tin YES
10-562-6-044
10-562-6-044
10-562-6-044
0.698" - Double Turret/Double Turret Swage Mount 0.230" 3/16 0.159 Brass Bright Tin YES
10-441-1-04
10-441-1-04
10-441-1-04
0.419" - - Swage Mount 0.075" 1/32 0.1405 Brass Electro-Tin YES
10-460-1-04
10-460-1-04
10-460-1-04
0.334" - - Swage Mount 0.053" 1/32 0.063 Brass Electro-Tin YES
10-421-3-044
10-421-3-044
10-421-3-044
0.604" - - Swage Mount 0.135" 3/32 0.116 Brass Bright Tin YES
10-240-3-04
10-240-3-04
10-240-3-04
0.499" - - Swage Mount 0.135" 3/32 0.116 Brass Electro-Tin YES
