Commercial
Non-Insulated
Terminals

Filter
09-0078-11-088
09-0078-11-088
09-0078-11-088
0.193" - - Swage Mount 0.037" 1/64 0.076 Brass Bright Tin-Lead NO
09-0050-2-04
09-0050-2-04
09-0050-2-04
0.421" - - Swage Mount 0.109" 1/16 0.140 Brass Electro-Tin YES
10-871-2-044
10-871-2-044
10-871-2-044
0.428" 0.030 - Swage Mount 0.084" 1/16 0.067 Brass Bright Tin YES
10-869-2-044
10-869-2-044
10-869-2-044
0.365" 0.030 - Swage Mount 0.084" 1/16 0.067 Brass Bright Tin YES
10-869-4-05
10-869-4-05
10-869-4-05
0.428" 0.030 - Swage Mount 0.147" 1/8 0.067 Brass Electro Solder NO
10-869-2-03
10-869-2-03
10-869-2-03
0.365" 0.030 - Swage Mount 0.084" 1/16 0.067 Brass Gold YES
10-812-3-035
10-812-3-035
10-812-3-035
0.625" - Turret/Turret Swage Mount 0.125" 3/32 0.147 Brass Gold YES
10-470-2-01
10-470-2-01
10-470-2-01
0.480" - - Swage Mount 0.105" 1/16 0.154 Brass Silver YES
10-815-1-01
10-815-1-01
10-815-1-01
0.275" - - Swage Mount 0.075" 1/32 0.1495 Brass Silver YES
10-816-6-01
10-816-6-01
10-816-6-01
0.430" - - Swage Mount 0.230" 3/16 0.1495 Brass Silver YES
10-511-3-035
10-511-3-035
10-511-3-035
0.807" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.116 Brass Gold YES
10-511-4-035
10-511-4-035
10-511-4-035
0.837" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.116 Brass Gold YES
10-556-2-035
10-556-2-035
10-556-2-035
0.386" - Turret/Turret Swage Mount 0.105" 1/16 0.116 Brass Gold YES
10-556-3-035
10-556-3-035
10-556-3-035
0.416" - Turret/Turret Swage Mount 0.135" 3/32 0.116 Brass Gold YES
10-503-1-03
10-503-1-03
10-503-1-03
0.401" - Double Turret/Double Turret Swage Mount 0.051" 1/32 0.076 Brass Gold YES
10-562-6-03
10-562-6-03
10-562-6-03
0.698" - Double Turret/Double Turret Swage Mount 0.230" 3/16 0.159 Brass Gold YES
09-0269-2-03
09-0269-2-03
09-0269-2-03
0.265" - - Press Fit/Solder 0.130" 1/16 TO 3/32 0.055 Brass Gold YES
09-8041-3-03
09-8041-3-03
09-8041-3-03
0.283" 0.032 TURRET/PC PIN Swage Mount 0.115" 3/32 0.067 Brass Gold YES
09-0174-1-035
09-0174-1-035
09-0174-1-035
0.205" - - Press Fit/Solder 0.158" 3/32 0.094 Brass Gold YES
10-504-1-035
10-504-1-035
10-504-1-035
0.469" - Double Turret/Double Turret Swage Mount 0.062" 1/32 0.094 Brass Gold YES
