Commercial
Non-Insulated
Terminals

Filter
10-511-3-04
10-511-3-04
10-511-3-04
0.807" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.116 Brass Electro-Tin YES
09-8480-3-04
09-8480-3-04
09-8480-3-04
0.263" 0.025 - Swage Mount 0.113" 3/32 0.0465 Brass Electro-Tin YES
09-0033-1-04
09-0033-1-04
09-0033-1-04
0.563" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Electro-Tin YES
10-605-3-04
10-605-3-04
10-605-3-04
0.475" - - Swage Mount 0.135" 3/32 0.090 Brass Electro-Tin YES
10-924-1-044
10-924-1-044
10-924-1-044
0.275" 0.025 - - - - - Brass Bright Tin YES
10-812-6-044
10-812-6-044
10-812-6-044
0.719" - Turret/Turret Swage Mount 0.219" 3/16 0.147 Brass Bright Tin YES
10-416-1-04
10-416-1-04
10-416-1-04
0.209" - - Swage Mount 0.053" 1/32 0.064 Brass Electro-Tin YES
10-615-2-05
10-615-2-05
10-615-2-05
0.445" - - Swage Mount 0.105" 1/16 0.090 Brass Electro Solder NO
09-0078-2-04
09-0078-2-04
09-0078-2-04
0.252" - - Swage Mount 0.096" 1/16 0.076 Brass Electro-Tin YES
10-419-4-01
10-419-4-01
10-419-4-01
0.556" - SLOTTED/DOUBLE TURRET Swage Mount 0.165" 1/8 0.094 Brass Silver YES
10-805-6-095
10-805-6-095
10-805-6-095
0.524" - - Swage Mount 0.234" 3/16 0.094 Brass Hot Solder Dip NO
10-462-2-095
10-462-2-095
10-462-2-095
0.240" - - Swage Mount 0.084" 1/16 0.052 Brass Hot Solder Dip NO
10-460-3-01
10-460-3-01
10-460-3-01
0.396" - - Swage Mount 0.115" 3/32 0.063 Brass Silver YES
10-248-2-01
10-248-2-01
10-248-2-01
0.417" - - Swage Mount 0.105" 1/16 0.073 Brass Silver YES
10-456-2-05
10-456-2-05
10-456-2-05
0.421" - - Swage Mount 0.109" 1/16 0.116 Brass Electro Solder NO
09-0180-1-095
09-0180-1-095
09-0180-1-095
0.289" - - Swage Mount 0.062" 1/32 0.062 Brass Hot Solder Dip NO
10-215-6-01
10-215-6-01
10-215-6-01
0.363" - - Swage Mount 0.209" 3/16 0.063 Brass Silver YES
10-349-4-01
10-349-4-01
10-349-4-01
0.500" - - Swage Mount 0.172" 1/8 0.116 Brass Silver YES
10-472-2-01
10-472-2-01
10-472-2-01
0.449" - - Swage Mount 0.105" 1/16 0.116 Brass Silver YES
10-515-2-01
10-515-2-01
10-515-2-01
0.871" 0.094 TURRET/PIN Swage Mount 0.105" 1/16 0.185 Brass Silver YES
