Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
09-7195-2-044	0.433"	0.040	-	RIVET MOUNT	0.095"	1/16	0.0625	Brass	Bright Tin	YES
09-7196-2-01	0.281"	0.030	-	RIVET MOUNT	0.083"	1/16	0.035	Brass	Silver	YES
09-7131-2-01	0.613"	0.0405	-	RIVET MOUNT	0.087"	1/16	0.044	Brass	Silver	YES
09-7133-2-01	1.013"	0.0405	-	RIVET MOUNT	0.087"	1/16	0.044	Brass	Silver	YES
09-7172-2-035	0.341"	-	-	RIVET MOUNT	0.089"	1/16	0.035	Brass	Gold	YES
09-7175-2-035	0.483"	-	-	RIVET MOUNT	0.088"	1/16	0.044	Brass	Gold	YES
09-7193-2-035	0.494"	-	-	RIVET MOUNT	0.125"	1/16	0.116	Brass	Gold	YES
09-7171-2-035	0.235"	-	-	RIVET MOUNT	0.082"	1/16	0.035	Brass	Gold	YES
09-7110-1-035	0.305"	0.023	-	RIVET MOUNT	0.051"	1/32	0.032	Brass	Gold	YES
09-7128-1-035	0.782"	0.0405	-	RIVET MOUNT	0.056"	1/32	0.044	Brass	Gold	YES
09-7130-1-035	0.982"	0.0405	-	RIVET MOUNT	0.056"	1/32	0.044	Brass	Gold	YES
09-7126-1-035	0.422"	0.0405	-	RIVET MOUNT	0.056"	1/32	0.044	Brass	Gold	YES
09-8777-2-035	0.215"	0.020	-	Swage Mount	0.085"	1/16	0.031	Brass	Gold	YES
09-7186-4-035	0.300"	-	-	RIVET MOUNT	0.150"	1/8	0.044	Brass	Gold	YES
09-7186-2-035	0.237"	-	-	RIVET MOUNT	0.087"	1/16	0.044	Brass	Gold	YES
09-7113-2-035	0.203"	0.030	-	RIVET MOUNT	0.083"	1/16	0.035	Brass	Gold	YES
09-7170-1B-035	0.166"	-	-	RIVET MOUNT	0.067"	3/64	0.035	Brass	Gold	YES
09-7192-2-035	0.251"	-	-	RIVET MOUNT	0.100"	1/16	0.073	Brass	Gold	YES
09-7178-2-035	0.544"	-	-	RIVET MOUNT	0.123"	1/16	0.116	Brass	Gold	YES
09-7159-2-035	0.318"	0.040	-	RIVET MOUNT	0.095"	1/16	0.0625	Brass	Gold	YES
