Commercial
Insulated
Pin Terminals

Filter
1127-02-04418
1127-02-04418
1127-02-04418
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1137-02-0514
1137-02-0514
1137-02-0514
0.552" 0.030 (+0.000/-0.005) Pin/Slotted Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Yellow NO
1137-02-0519
1137-02-0519
1137-02-0519
0.552" 0.030 (+0.000/-0.005) Pin/Slotted Press Fit 1/16 0.070 Brass Electro Solder - - PTFE White NO
1139-02-0513
1139-02-0513
1139-02-0513
0.383" 0.030 (+0.003/-0.000) Pin/Pin Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Orange NO
1111-02-04415
1111-02-04415
1111-02-04415
0.535" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.101 Brass Bright Tin - - PTFE Green YES
1112-02-08812
1112-02-08812
1112-02-08812
0.215" - - Press Fit 1/64 0.086 Brass Bright Tin-Lead - - PTFE Red NO
1111-02-04416
1111-02-04416
1111-02-04416
0.535" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.101 Brass Bright Tin - - PTFE Blue YES
1125-02-08817
1125-02-08817
1125-02-08817
0.578" - - 2-56 Nut 7/64 0.094 Brass Bright Tin-Lead Electro-Tin Brass PTFE Violet NO
1111-02-04419
1111-02-04419
1111-02-04419
0.535" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.101 Brass Bright Tin - - PTFE White YES
1132-02-08815
1132-02-08815
1132-02-08815
0.645" 0.080 - Solder 7/32 0.086 Brass Bright Tin-Lead - - PTFE Green NO
1130-02-08813
1130-02-08813
1130-02-08813
1.870" (0.030)/(0.040) Pin/Pin Press Fit 7/32 0.172 Brass Bright Tin-Lead - - PTFE Orange NO
1111-02-04418
1111-02-04418
1111-02-04418
0.535" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.101 Brass Bright Tin - - PTFE Gray NO
1139-02-0515
1139-02-0515
1139-02-0515
0.383" 0.030 (+0.003/-0.000) Pin/Pin Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Green NO
1122-01-04413
1122-01-04413
1122-01-04413
0.250" - - Press Fit 1/64 0.070 Brass Bright Tin - - PTFE Orange NO
1139-02-0518
1139-02-0518
1139-02-0518
0.383" 0.030 (+0.003/-0.000) Pin/Pin Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Gray NO
1103-02-08813
1103-02-08813
1103-02-08813
0.262" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1103-02-08815
1103-02-08815
1103-02-08815
0.262" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1103-02-08817
1103-02-08817
1103-02-08817
0.262" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1103-02-08818
1103-02-08818
1103-02-08818
0.262" - - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
1100-02-0419
1100-02-0419
1100-02-0419
0.213" 0.040 - Press Fit 3/64 0.086 Brass Electro-Tin - - PTFE White YES
