Commercial
Insulated
Pin Terminals

Filter
1123-05-08816
1123-05-08816
1123-05-08816
0.947" 0.050 TIP/SLOTTED Press Fit 7/32 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1123-05-08818
1123-05-08818
1123-05-08818
0.947" 0.050 TIP/SLOTTED Press Fit 7/32 0.158 Brass Bright Tin-Lead - - PTFE Gray NO
1112R-05-0313
1112R-05-0313
1112R-05-0313
0.200" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Orange NO
1130R-05-0516
1130R-05-0516
1130R-05-0516
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Blue NO
1157R-05-0511
1157R-05-0511
1157R-05-0511
0.865" 0.050 TURRET/PIN Press Fit 7/32 0.158 Brass Electro Solder - - PTFE Brown NO
1123-05-08819
1123-05-08819
1123-05-08819
0.947" 0.050 TIP/SLOTTED Press Fit 7/32 0.158 Brass Bright Tin-Lead - - PTFE White NO
1133R-05-0412
1133R-05-0412
1133R-05-0412
0.450" 0.040 TURRET/PIN Press Fit 1/32 0.136 Brass Electro-Tin - - PTFE Red NO
1125-05-0417
1125-05-0417
1125-05-0417
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro-Tin Electro-Tin Brass PTFE Violet YES
1110-05-0316
1110-05-0316
1110-05-0316
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Gold - - PTFE Blue YES
1102-05-0117
1102-05-0117
1102-05-0117
0.359" - - Press Fit 1/16 0.091 Brass Silver - - PTFE Violet YES
1102-05-0113
1102-05-0113
1102-05-0113
0.359" - - Press Fit 1/16 0.091 Brass Silver - - PTFE Orange NO
1121R-05-0512
1121R-05-0512
1121R-05-0512
0.493" 0.040 Turret/Tip Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Red NO
1157-05-0513
1157-05-0513
1157-05-0513
0.865" 0.050 TURRET/PIN Press Fit 7/32 0.158 Brass Electro Solder - - PTFE Orange NO
1157R-05-0512
1157R-05-0512
1157R-05-0512
0.865" 0.050 TURRET/PIN Press Fit 7/32 0.158 Brass Electro Solder - - PTFE Red NO
1127-05-0312
1127-05-0312
1127-05-0312
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Gold Electro-Tin Brass DIALLYL PHTHALATE Red YES
1123-05-04419
1123-05-04419
1123-05-04419
0.947" 0.050 TIP/SLOTTED Press Fit 7/32 0.158 Brass Bright Tin - - PTFE White YES
1130-05-0314
1130-05-0314
1130-05-0314
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Yellow NO
1106-05-0518
1106-05-0518
1106-05-0518
0.540" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Gray NO
1113-05-08819
1113-05-08819
1113-05-08819
0.460" - - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE White NO
1114-05-0317
1114-05-0317
1114-05-0317
0.317" 0.040 - Press Fit 1/32 0.086 Brass Gold - - PTFE Violet YES
