Commercial
Insulated
Pin Terminals

Filter
1131-03-04419
1131-03-04419
1131-03-04419
0.562" (0.040)/(0.050) Pin/Tip Press Fit 3/32 0.172 Brass Bright Tin - - PTFE White YES
1124-03-0517
1124-03-0517
1124-03-0517
1.274" 0.050 THREAD/TIP Press Fit Up to 3/8 0.158 Brass Electro Solder - - PTFE Violet NO
1175-022-0518
1175-022-0518
1175-022-0518
0.455" 0.047 - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Gray NO
1124-02-0110
1124-02-0110
1124-02-0110
1.024" 0.050 THREAD/TIP Press Fit Up to 1/4 0.158 Brass Silver - - PTFE Black YES
1133-02-0314
1133-02-0314
1133-02-0314
0.836" 0.040 DOUBLE TURRET/PIN Press Fit Up to 3/16 0.136 Brass Gold - - PTFE Yellow NO
1129-02-04415
1129-02-04415
1129-02-04415
2.000" 0.030 TURRET/PIN Press Fit Up to 1/4 0.172 Brass Bright Tin - - PTFE Green YES
1175-011-0417
1175-011-0417
1175-011-0417
0.609" 0.047 Pin/Pin PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Violet YES
1111-01-04419
1111-01-04419
1111-01-04419
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE White YES
1111-01-08817
1111-01-08817
1111-01-08817
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Violet NO
1105-01-08818
1105-01-08818
1105-01-08818
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Bright Tin-Lead - - PTFE Gray NO
1133-01-08815
1133-01-08815
1133-01-08815
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1111R-01-0316
1111R-01-0316
1111R-01-0316
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.086 Brass Gold - - PTFE Blue YES
1118-01-08817
1118-01-08817
1118-01-08817
0.312" 0.040 Pin/Pin Press Fit 1/16 0.093 Brass Bright Tin-Lead - - PTFE Violet NO
1135-01-08818
1135-01-08818
1135-01-08818
0.510" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Bright Tin-Lead - - PTFE Gray NO
1135-01-08812
1135-01-08812
1135-01-08812
0.510" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Bright Tin-Lead - - PTFE Red NO
1175-451-04416
1175-451-04416
1175-451-04416
0.662" - DOUBLE TURRET/SLOTTED PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Blue YES
09-2090-1-0418
09-2090-1-0418
09-2090-1-0418
1.260" 0.040 (+0.001/-0.005) Pin/Pin Press Fit 1/32 0.076 Brass Electro-Tin - - PTFE Gray NO
09-2121-1-08817
09-2121-1-08817
09-2121-1-08817
0.275" - - Press Fit 5/64 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1107-15-0113
1107-15-0113
1107-15-0113
0.572" 0.040 Pin/Pin Press Fit 3/32 0.158 Brass Silver - - PTFE Orange NO
1111R-15-0112
1111R-15-0112
1111R-15-0112
0.609" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Silver - - PTFE Red NO
