Commercial
Insulated
Pin Terminals

Filter
1123-72-0317
1123-72-0317
1123-72-0317
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Gold - - PTFE Violet YES
1110-72-0413
1110-72-0413
1110-72-0413
0.550" 0.030 Pin/Pin Press Fit 1/16 0.069 Brass Electro-Tin - - PTFE Orange NO
1110-72-0411
1110-72-0411
1110-72-0411
0.550" 0.030 Pin/Pin Press Fit 1/16 0.069 Brass Electro-Tin - - PTFE Brown NO
1127-72-08819
1127-72-08819
1127-72-08819
0.875" - - 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE White NO
1123-72-0112
1123-72-0112
1123-72-0112
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Silver - - PTFE Red NO
1127-72-0515
1127-72-0515
1127-72-0515
0.875" - - 6-32 Nut 1/8 0.144 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Green NO
1127-72-0511
1127-72-0511
1127-72-0511
0.875" - - 6-32 Nut 1/8 0.144 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Brown NO
1127-72-0416
1127-72-0416
1127-72-0416
0.875" - - 6-32 Nut 1/8 0.144 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1125-72-08817
1125-72-08817
1125-72-08817
1.172" - - Swage Mount 1/16 0.125 Brass Bright Tin-Lead ZINC Brass PTFE Violet NO
1123-72-08813
1123-72-08813
1123-72-08813
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1125-72-0419
1125-72-0419
1125-72-0419
1.172" - - Swage Mount 1/16 0.125 Brass Electro-Tin ZINC Brass PTFE White YES
1123-72-04417
1123-72-04417
1123-72-04417
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Violet YES
1123-72-04412
1123-72-04412
1123-72-04412
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Red NO
1114-72-0118
1114-72-0118
1114-72-0118
0.310" - - Press Fit 1/64 0.136 Brass Silver - - PTFE Gray NO
1114-72-0119
1114-72-0119
1114-72-0119
0.310" - - Press Fit 1/64 0.136 Brass Silver - - PTFE White YES
1127-72-0510
1127-72-0510
1127-72-0510
0.875" - - 6-32 Nut 1/8 0.144 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Black NO
1127-72-08816
1127-72-08816
1127-72-08816
0.875" - - 6-32 Nut 1/8 0.144 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Blue NO
1110-72-0116
1110-72-0116
1110-72-0116
0.550" 0.030 Pin/Pin Press Fit 1/16 0.069 Brass Silver - - PTFE Blue YES
1123-72-0411
1123-72-0411
1123-72-0411
0.495" 0.040 TIP/SLOTTED Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Brown NO
1102R-72-0417
1102R-72-0417
1102R-72-0417
0.350" - - Press Fit 1/16 0.166 Brass Electro-Tin - - PTFE Violet YES
