Commercial
Insulated
Pin Terminals

Filter
1152R-03-08813
1152R-03-08813
1152R-03-08813
0.415" 0.040 - Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1129-03-08818
1129-03-08818
1129-03-08818
2.000" 0.030 TURRET/PIN Press Fit 1/8 0.172 Brass Bright Tin-Lead - - PTFE Gray NO
1108-03-0116
1108-03-0116
1108-03-0116
0.640" - Double Turret/Double Turret Press Fit 1/8 0.156 Brass Silver - - PTFE Blue YES
1175-023-08814
1175-023-08814
1175-023-08814
0.487" 0.047 - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Yellow NO
1108-02-0413
1108-02-0413
1108-02-0413
2.287" - Double Turret/Double Turret Press Fit 7/8 0.205 Brass Electro-Tin - - PTFE Orange NO
1130-02-0410
1130-02-0410
1130-02-0410
1.870" (0.030)/(0.040) Pin/Pin Press Fit 7/32 0.172 Brass Electro-Tin - - PTFE Black YES
1137-01-0412
1137-01-0412
1137-01-0412
0.510" 0.030 (+0.000/-0.005) Pin/Slotted Press Fit 1/16 0.070 Brass Electro-Tin - - PTFE Red NO
1175-752-0514
1175-752-0514
1175-752-0514
0.686" - DOUBLE TURRET/SLOTTED PRESS LOCK 1/16 0.154 (+0.003/-0.001) Brass Electro Solder - - PTFE Yellow NO
1127-75-0415
1127-75-0415
1127-75-0415
0.719" - - Swage Mount 1/16 0.104 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Green YES
1125-75-04412
1125-75-04412
1125-75-04412
0.634" - - Swage Mount 1/32 0.194 Brass Bright Tin ZINC Brass PTFE Red NO
1125-72-0112
1125-72-0112
1125-72-0112
1.172" - - Swage Mount 1/16 0.125 Brass Silver ZINC Brass PTFE Red NO
1175-711-0112
1175-711-0112
1175-711-0112
0.548" - DOUBLE Turret/Turret PRESS LOCK 1/32 0.154 (+0.003/-0.001) Brass Silver - - PTFE Red NO
1100R-69-04416
1100R-69-04416
1100R-69-04416
0.220" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Blue YES
1100R-68-0116
1100R-68-0116
1100R-68-0116
0.420" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Blue YES
1100R-68-0113
1100R-68-0113
1100R-68-0113
0.420" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Orange NO
1127-67-0117
1127-67-0117
1127-67-0117
0.610" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Violet YES
1127-66-0316
1127-66-0316
1127-66-0316
0.454" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE Blue YES
1127-66-04415
1127-66-04415
1127-66-04415
0.454" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Green YES
1100R-35-04417
1100R-35-04417
1100R-35-04417
0.500" 0.040 - Press Fit Up to 3/16 0.136 Brass Bright Tin - - PTFE Violet YES
1110-40-0114
1110-40-0114
1110-40-0114
0.675" 0.040 Pin/Pin Press Fit 1/8 0.152 Brass Silver - - PTFE Yellow NO
