Commercial
Insulated
Pin Terminals

Filter
1110R-16-08816
1110R-16-08816
1110R-16-08816
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1110-16-04414
1110-16-04414
1110-16-04414
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Yellow NO
1110-16-04412
1110-16-04412
1110-16-04412
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Red NO
1114R-16-08813
1114R-16-08813
1114R-16-08813
0.296" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1110-16-04411
1110-16-04411
1110-16-04411
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Brown NO
1110-16-04410
1110-16-04410
1110-16-04410
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Black YES
1114R-16-08814
1114R-16-08814
1114R-16-08814
0.296" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1125-16-0312
1125-16-0312
1125-16-0312
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold Electro-Tin Brass PTFE Red NO
1110R-16-04413
1110R-16-04413
1110R-16-04413
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Orange NO
1114R-16-08815
1114R-16-08815
1114R-16-08815
0.296" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1114R-16-08816
1114R-16-08816
1114R-16-08816
0.296" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1110R-16-04416
1110R-16-04416
1110R-16-04416
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Blue YES
1155R-16-0411
1155R-16-0411
1155R-16-0411
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Brown NO
1121-16-0515
1121-16-0515
1121-16-0515
0.740" 0.050 Turret/Tip Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Green NO
1114R-16-0410
1114R-16-0410
1114R-16-0410
0.296" 0.040 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Black YES
1114R-16-0413
1114R-16-0413
1114R-16-0413
0.296" 0.040 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1155R-16-0410
1155R-16-0410
1155R-16-0410
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Black YES
1155-16-0418
1155-16-0418
1155-16-0418
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Gray NO
1106-16-04417
1106-16-04417
1106-16-04417
0.890" - - Press Fit 5/32 0.205 Brass Bright Tin - - PTFE Violet YES
1102-16-04413
1102-16-04413
1102-16-04413
0.428" - - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Orange NO
