Commercial
Insulated
Pin Terminals

Filter
1102R-21-0418
1102R-21-0418
1102R-21-0418
0.455" - - Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Gray NO
1127-32-0417
1127-32-0417
1127-32-0417
0.844" - - 6-32 Nut 1/8 0.144 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Violet YES
1127-32-0418
1127-32-0418
1127-32-0418
0.844" - - 6-32 Nut 1/8 0.144 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1112-32-0417
1112-32-0417
1112-32-0417
0.351" - - Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Violet YES
1125-32-04413
1125-32-04413
1125-32-04413
0.630" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin Electro-Tin Brass PTFE Orange NO
1111-32-04418
1111-32-04418
1111-32-04418
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.162 Brass Bright Tin - - PTFE Gray NO
1125-32-04412
1125-32-04412
1125-32-04412
0.630" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin Electro-Tin Brass PTFE Red NO
1102-32-0518
1102-32-0518
1102-32-0518
0.468" - - Press Fit 3/32 0.152 Brass Electro Solder - - PTFE Gray NO
1153-32-0318
1153-32-0318
1153-32-0318
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Gold - - PTFE Gray NO
1110-32-0511
1110-32-0511
1110-32-0511
0.710" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro Solder - - PTFE Brown NO
1153-32-0317
1153-32-0317
1153-32-0317
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Gold - - PTFE Violet YES
1112-32-0510
1112-32-0510
1112-32-0510
0.351" - - Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Black NO
1112-32-0514
1112-32-0514
1112-32-0514
0.351" - - Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Yellow NO
1112-32-0518
1112-32-0518
1112-32-0518
0.351" - - Press Fit 3/32 0.136 Brass Electro Solder - - PTFE Gray NO
1121-32-04414
1121-32-04414
1121-32-04414
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Bright Tin - - PTFE Yellow NO
1121-32-04413
1121-32-04413
1121-32-04413
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Bright Tin - - PTFE Orange NO
1126-32-08819
1126-32-08819
1126-32-08819
1.172" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin-Lead ZINC Brass PTFE White NO
1126-32-08817
1126-32-08817
1126-32-08817
1.172" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin-Lead ZINC Brass PTFE Violet NO
1121-32-04411
1121-32-04411
1121-32-04411
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Bright Tin - - PTFE Brown NO
1121-32-04410
1121-32-04410
1121-32-04410
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Bright Tin - - PTFE Black YES
