Commercial
Insulated
Pin Terminals

Filter
1103-08-04414
1103-08-04414
1103-08-04414
0.320" - - Press Fit 3/32 0.152 Brass Bright Tin - - PTFE Yellow NO
1156-08-0414
1156-08-0414
1156-08-0414
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Yellow NO
1123-08-04415
1123-08-04415
1123-08-04415
1.197" 0.050 TIP/SLOTTED Press Fit 15/32 0.158 Brass Bright Tin - - PTFE Green YES
1156-08-0415
1156-08-0415
1156-08-0415
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Green YES
1156-08-0416
1156-08-0416
1156-08-0416
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Blue YES
1135-08-04415
1135-08-04415
1135-08-04415
0.425" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Green YES
1135-08-04414
1135-08-04414
1135-08-04414
0.425" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Yellow NO
1131-08-08819
1131-08-08819
1131-08-08819
0.739" (0.040)/(0.081) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE White NO
1153-08-0511
1153-08-0511
1153-08-0511
0.580" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Brown NO
1135-08-0312
1135-08-0312
1135-08-0312
0.425" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Gold - - PTFE Red NO
1131-08-08816
1131-08-08816
1131-08-08816
0.739" (0.040)/(0.081) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Blue NO
1131-08-08815
1131-08-08815
1131-08-08815
0.739" (0.040)/(0.081) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Green NO
1131-08-08813
1131-08-08813
1131-08-08813
0.739" (0.040)/(0.081) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Orange NO
1131-08-08811
1131-08-08811
1131-08-08811
0.739" (0.040)/(0.081) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Brown NO
1131-08-08810
1131-08-08810
1131-08-08810
0.739" (0.040)/(0.081) Pin/Tip Press Fit Up to 1/4 0.172 Brass Bright Tin-Lead - - PTFE Black NO
1103-08-0312
1103-08-0312
1103-08-0312
0.320" - - Press Fit 3/32 0.152 Brass Gold - - PTFE Red NO
1135-08-04413
1135-08-04413
1135-08-04413
0.425" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Orange NO
1111-08-0412
1111-08-0412
1111-08-0412
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Electro-Tin - - PTFE Red NO
1111-08-08813
1111-08-08813
1111-08-08813
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Orange NO
1156-08-0418
1156-08-0418
1156-08-0418
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Gray NO
