Commercial
Insulated
Pin Terminals

Filter
1151-05-0514
1151-05-0514
1151-05-0514
0.350" - - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1130R-05-0311
1130R-05-0311
1130R-05-0311
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Brown NO
1151-05-0513
1151-05-0513
1151-05-0513
0.350" - - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Orange NO
1130R-05-0314
1130R-05-0314
1130R-05-0314
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Yellow NO
1130R-05-0315
1130R-05-0315
1130R-05-0315
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Green YES
1102-38-04416
1102-38-04416
1102-38-04416
0.485" - - Press Fit 1/8 0.152 Brass Bright Tin - - PTFE Blue YES
1131-05-0512
1131-05-0512
1131-05-0512
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Red NO
1131-05-0514
1131-05-0514
1131-05-0514
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Yellow NO
1130R-05-0317
1130R-05-0317
1130R-05-0317
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Gold - - PTFE Violet YES
1151-38-04414
1151-38-04414
1151-38-04414
0.390" - - Press Fit 1/16 0.158 Brass Bright Tin - - PTFE Yellow NO
1130R-05-0319
1130R-05-0319
1130R-05-0319
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Gold - - PTFE White YES
1131-05-04419
1131-05-04419
1131-05-04419
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Bright Tin - - PTFE White YES
1131-05-0515
1131-05-0515
1131-05-0515
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Green NO
1131-05-0313
1131-05-0313
1131-05-0313
0.562" (0.040)/(0.081) Pin/Tip Press Fit 3/32 0.172 Brass Gold - - PTFE Orange NO
1160-05-08812
1160-05-08812
1160-05-08812
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1160-05-0314
1160-05-0314
1160-05-0314
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Gold - - PTFE Yellow NO
1110R-05-0312
1110R-05-0312
1110R-05-0312
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Gold - - PTFE Red NO
1110R-05-0317
1110R-05-0317
1110R-05-0317
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Gold - - PTFE Violet YES
1100-05-08817
1100-05-08817
1100-05-08817
0.262" 0.040 - Press Fit 3/64 0.086 Brass Bright Tin-Lead - - PTFE Violet NO
1103R-05-0310
1103R-05-0310
1103R-05-0310
0.455" - - Press Fit 5/32 0.136 Brass Gold - - PTFE Black YES
