Commercial
Insulated
Pin Terminals

Filter
1177-32-08816
1177-32-08816
1177-32-08816
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1177-32-08814
1177-32-08814
1177-32-08814
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1119-32-0416
1119-32-0416
1119-32-0416
0.836" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Blue YES
1160-22-08816
1160-22-08816
1160-22-08816
0.350" - - Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Blue NO
1177-32-0519
1177-32-0519
1177-32-0519
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Electro Solder - - PTFE White NO
1177-32-0516
1177-32-0516
1177-32-0516
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Electro Solder - - PTFE Blue NO
1118-32-04410
1118-32-04410
1118-32-04410
0.346" - TURRET/SLOTTED Press Fit 3/32 0.093 Brass Bright Tin - - PTFE Black YES
1112-32-08814
1112-32-08814
1112-32-08814
0.351" - - Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1102-32-0510
1102-32-0510
1102-32-0510
0.468" - - Press Fit 3/32 0.152 Brass Electro Solder - - PTFE Black NO
1127-32-04417
1127-32-04417
1127-32-04417
0.844" - - 6-32 Nut 1/8 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Violet YES
1177-32-0515
1177-32-0515
1177-32-0515
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Electro Solder - - PTFE Green NO
1127-32-04414
1127-32-04414
1127-32-04414
0.844" - - 6-32 Nut 1/8 0.144 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Yellow YES
1177-32-0514
1177-32-0514
1177-32-0514
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1177-32-0510
1177-32-0510
1177-32-0510
0.500" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/32 - 1/16 0.136 Brass Electro Solder - - PTFE Black NO
1119-32-0417
1119-32-0417
1119-32-0417
0.836" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Violet YES
1153-32-0516
1153-32-0516
1153-32-0516
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Blue NO
1153-32-0514
1153-32-0514
1153-32-0514
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Yellow NO
1153-32-0512
1153-32-0512
1153-32-0512
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Red NO
1153-32-0510
1153-32-0510
1153-32-0510
0.515" 0.040 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Black NO
1100-32-0112
1100-32-0112
1100-32-0112
0.370" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Red NO
