Commercial
Insulated
Pin Terminals

Filter
1114R-09-0318
1114R-09-0318
1114R-09-0318
0.193" 0.050 - Press Fit 1/32 0.113 Brass Gold - - PTFE Gray NO
1114R-09-0319
1114R-09-0319
1114R-09-0319
0.193" 0.050 - Press Fit 1/32 0.113 Brass Gold - - PTFE White YES
1156-09-0310
1156-09-0310
1156-09-0310
0.609" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Gold - - PTFE Black YES
1110-09-0319
1110-09-0319
1110-09-0319
0.375" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Gold - - PTFE White YES
1127-09-08816
1127-09-08816
1127-09-08816
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Blue NO
1127-09-08817
1127-09-08817
1127-09-08817
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Violet NO
1103R-09-0517
1103R-09-0517
1103R-09-0517
0.320" - - Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Violet NO
1135-09-0412
1135-09-0412
1135-09-0412
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Red NO
1127-09-04416
1127-09-04416
1127-09-04416
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1100-09-08819
1100-09-08819
1100-09-08819
0.350" 0.040 - Press Fit 3/32 0.098 Brass Bright Tin-Lead - - PTFE White NO
1127-09-04414
1127-09-04414
1127-09-04414
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Yellow YES
1127-09-04412
1127-09-04412
1127-09-04412
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Red YES
1127-09-04410
1127-09-04410
1127-09-04410
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Black YES
1123-09-08815
1123-09-08815
1123-09-08815
1.197" 0.050 TIP/SLOTTED Press Fit 1/2 0.158 Brass Bright Tin-Lead - - PTFE Green NO
1106-09-0314
1106-09-0314
1106-09-0314
0.603" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Yellow NO
1106-09-0313
1106-09-0313
1106-09-0313
0.603" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Orange NO
1103R-09-0515
1103R-09-0515
1103R-09-0515
0.320" - - Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Green NO
1123-09-0416
1123-09-0416
1123-09-0416
1.197" 0.050 TIP/SLOTTED Press Fit 1/2 0.158 Brass Electro-Tin - - PTFE Blue YES
1135-09-0311
1135-09-0311
1135-09-0311
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Gold - - PTFE Brown NO
1121-09-0510
1121-09-0510
1121-09-0510
0.385" 0.040 Turret/Tip Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Black NO
