Commercial
Insulated
Pin Terminals

Filter
1104-53-08819
1104-53-08819
1104-53-08819
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE White NO
1102-53-08817
1102-53-08817
1102-53-08817
0.431" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Violet NO
1102-53-0117
1102-53-0117
1102-53-0117
0.431" - - Press Fit 1/8 0.158 Brass Silver - - PTFE Violet YES
1106-53-0111
1106-53-0111
1106-53-0111
0.641" - - Press Fit Up to 1/4 0.205 Brass Silver - - PTFE Brown NO
1125-53-0311
1125-53-0311
1125-53-0311
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Gold Electro-Tin Brass PTFE Brown NO
1114-08-0318
1114-08-0318
1114-08-0318
0.310" 0.040 - Press Fit 3/32 0.108 Brass Gold - - PTFE Gray NO
1123-03-0319
1123-03-0319
1123-03-0319
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Gold - - PTFE White YES
1156-03-0113
1156-03-0113
1156-03-0113
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.086 Brass Silver - - PTFE Orange NO
1104-53-0119
1104-53-0119
1104-53-0119
0.555" - - Press Fit 1/8 0.158 Brass Silver - - PTFE White YES
1104-53-04412
1104-53-04412
1104-53-04412
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Red NO
1114-03-0518
1114-03-0518
1114-03-0518
0.215" 0.040 - Press Fit 1/64 0.086 Brass Electro Solder - - PTFE Gray NO
1110-53-0514
1110-53-0514
1110-53-0514
0.437" 0.050 TURRET/PIN Press Fit 3/32 0.172 Brass Electro Solder - - PTFE Yellow NO
1100R-66-0418
1100R-66-0418
1100R-66-0418
0.350" 0.040 - Press Fit 1/16 0.113 Brass Electro-Tin - - PTFE Gray NO
1115-53-04418
1115-53-04418
1115-53-04418
0.593" - Turret/Turret Press Fit 3/32 0.187 Brass Bright Tin - - PTFE Gray NO
1104-53-04411
1104-53-04411
1104-53-04411
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Brown NO
1127-53-0310
1127-53-0310
1127-53-0310
0.953" - - Swage Mount 3/16 0.147 Brass Gold ZINC Brass DIALLYL PHTHALATE Black YES
1104-03-0514
1104-03-0514
1104-03-0514
0.362" - - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Yellow NO
1104R-53-0110
1104R-53-0110
1104R-53-0110
0.555" - - Press Fit 1/8 0.158 Brass Silver - - PTFE Black YES
1177-53-0118
1177-53-0118
1177-53-0118
0.656" 0.030 Pin/Pin PRESS LOCK 1/32 - 1/16 0.115 Brass Silver - - PTFE Gray NO
1115-03-0513
1115-03-0513
1115-03-0513
0.367" 0.040 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Orange NO
