Commercial
Insulated
Pin Terminals

Filter
1106R-51-0316
1106R-51-0316
1106R-51-0316
0.150" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Blue YES
1110-16-0519
1110-16-0519
1110-16-0519
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Electro Solder - - PTFE White NO
1100R-51-04415
1100R-51-04415
1100R-51-04415
0.310" 0.040 - Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Green YES
1112R-05-0510
1112R-05-0510
1112R-05-0510
0.200" - - Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Black NO
1102-03-0512
1102-03-0512
1102-03-0512
0.350" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Red NO
1112R-05-0412
1112R-05-0412
1112R-05-0412
0.200" - - Press Fit 1/32 0.113 Brass Electro-Tin - - PTFE Red NO
1110-07-0312
1110-07-0312
1110-07-0312
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Gold - - PTFE Red NO
1112-06-0313
1112-06-0313
1112-06-0313
0.233" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Orange NO
1110-13-08818
1110-13-08818
1110-13-08818
0.325" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
1103R-08-08815
1103R-08-08815
1103R-08-08815
0.320" - - Press Fit 3/32 0.158 Brass Bright Tin-Lead - - PTFE Green NO
1102-83-08816
1102-83-08816
1102-83-08816
1.234" - - Press Fit 5/32 0.203 Brass Bright Tin-Lead - - PTFE Blue NO
1115-53-08815
1115-53-08815
1115-53-08815
0.593" - Turret/Turret Press Fit 3/32 0.187 Brass Bright Tin-Lead - - PTFE Green NO
1125-23-0415
1125-23-0415
1125-23-0415
0.822" - - 4-40 Nut Up to 3/16 0.120 Brass Electro-Tin Electro-Tin Brass PTFE Green YES
1114-25-0315
1114-25-0315
1114-25-0315
0.413" 0.085 - Press Fit 1/8 0.136 Brass Gold - - PTFE Green YES
1151-42-0315
1151-42-0315
1151-42-0315
0.800" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Green YES
1114-10-0317
1114-10-0317
1114-10-0317
0.225" 0.040 - Press Fit 1/32 0.113 Brass Gold - - PTFE Violet YES
1102R-22-0318
1102R-22-0318
1102R-22-0318
0.470" - - Press Fit 5/32 0.136 Brass Gold - - PTFE Gray NO
1102R-15-0318
1102R-15-0318
1102R-15-0318
0.375" - - Press Fit 3/32 0.136 Brass Gold - - PTFE Gray NO
1111-57-0316
1111-57-0316
1111-57-0316
0.680" 0.040 - Press Fit 1/8 0.158 Brass Gold - - PTFE Blue YES
1110-25-0416
1110-25-0416
1110-25-0416
0.535" 0.040 Pin/Pin Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Blue YES
