Commercial
Insulated
Pin Terminals

Filter
1102-82-04418
1102-82-04418
1102-82-04418
0.934" - - Press Fit 5/32 0.203 Brass Bright Tin - - PTFE Gray NO
1151-21-04414
1151-21-04414
1151-21-04414
0.509" - - Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Yellow NO
1100-32-04410
1100-32-04410
1100-32-04410
0.370" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Black YES
1112-02-04417
1112-02-04417
1112-02-04417
0.215" - - Press Fit 1/64 0.086 Brass Bright Tin - - PTFE Violet YES
1100-17-04417
1100-17-04417
1100-17-04417
0.305" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Violet YES
1102R-93-0315
1102R-93-0315
1102R-93-0315
0.415" - - Press Fit 1/8 0.136 Brass Gold - - PTFE Green YES
1151-38-04418
1151-38-04418
1151-38-04418
0.390" - - Press Fit 1/16 0.158 Brass Bright Tin - - PTFE Gray NO
1114-73-04413
1114-73-04413
1114-73-04413
0.320" - - Press Fit 1/32 0.136 Brass Bright Tin - - PTFE Orange NO
1126-25-04415
1126-25-04415
1126-25-04415
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin ZINC Brass PTFE Green YES
1175-513-04411
1175-513-04411
1175-513-04411
0.426" - - PRESS LOCK 3/32 0.189 (+0.003/-0.001) Brass Bright Tin - - PTFE Brown NO
1123R-75-04414
1123R-75-04414
1123R-75-04414
0.426" - - Press Fit 1/8 0.172 Brass Bright Tin - - PTFE Yellow NO
1100R-22-04414
1100R-22-04414
1100R-22-04414
0.310" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin - - PTFE Yellow NO
1125-40-0519
1125-40-0519
1125-40-0519
0.912" - - 4-40 Nut Up to 3/16 0.120 Brass Electro Solder Electro-Tin Brass PTFE White NO
1125-43-04412
1125-43-04412
1125-43-04412
0.750" - - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass PTFE Red NO
1121-15-0416
1121-15-0416
1121-15-0416
0.740" 0.050 Turret/Tip Press Fit 3/32 0.158 Brass Electro-Tin - - PTFE Blue YES
1126-35-0315
1126-35-0315
1126-35-0315
0.766" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Gold ZINC Brass PTFE Green YES
1110-28-0412
1110-28-0412
1110-28-0412
0.562" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Red NO
1110-07-04413
1110-07-04413
1110-07-04413
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Orange NO
1110-43-0419
1110-43-0419
1110-43-0419
1.875" 0.049 Pin/Pin Press Fit 1/16 0.156 Brass Electro-Tin - - PTFE White YES
1114R-19-0415
1114R-19-0415
1114R-19-0415
0.310" 0.085 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Green YES

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
